| | | Output: 4-20 mA DC = 0% to 100% RH. Sensing Element: Capacitive monolithic IC. Accuracy: Includes temperature, linearity, hysteresis, and repeatability. ±1% from 10% to 80% RH @ 25 to 35°C or ±2% from 0% to 90% RH @ 25°C (±3% from 0% to 90% RH @ 15 to 50°C) (±5% from 0% to 90% RH @ 0 to 82°C) | | Output: 4-20 mA DC over the specified temperature range. Sensing element: 1000 Q platinum; 2 lead resistance thermometer, 0.00385 TCR. Accuracy: Includes resistance thermometer tolerance, calibration accuracy, linearity, and ambient temperature effects. ±.75% of Temptran™ span for 32 to 122°F ambient. ±1.50% of Temptran™ span for -13 to 185°F ambient. AH439 Specification and order options | | |
| | | |
| | | |
| | | Model number: | | |
| | | AH439 | | |
| | | |
| | | Enclosure D: Duct mount, 8" probe length O: Outside Air/Wall mount, 4" probe length with shield, weather resistant enclosure S: Space mount W: Wall mount, 4" probe length, weather resistant enclosure R: Remote probe, 4" probe length | | |
| | | R | | |
| | | |
| | | AH429 Specification and order options | | |
| | | |
| | | | | | | | | | AH429 | Model number: | | | | R | Enclosure D: Duct mount, 8" probe length O: Outside Air/Wall mount, 4" probe length with shield, weather resistant enclosure S: Space mount W: Wall mount, 4" probe length, weather resistant enclosure R: Remote probe, 4" probe length | | | | 1 | Output 4 to 20 mA DC | | | | N10 | Calibration accuracy (humidity transmitter) N10: ±1% from 10% to 80% (25 to 35°C) with NIST certificate N20: ±2% from 0% to 90% (25 to 35°C) with NIST certificate S20: ±2% from 0% to 90% (25 to 35°C) | | | | T1 | Sensing element cover (omitted on "S" space mount models) T0= Sintered stainless steel; pressed on cover T1 = Sintered stainless steel; screw on cover T2= Slotted stainless steel; screw on cover (NA on "O" outside air models) | | | | To order enclosure D, O, S or W, stop here. To order enclosure R (remote probe), add: | | | | A | Probe mounting location A = Side mounting B = Bottom mounting | | | | 48 | Remote probe cable length (in inches) 48" and 96" are standard lengths | | | | AH429R1N10T1A48 = Sample part number | | | | | | | | | |
| | | |
| | | Outputs 4 to 20 mA DC | | |
| | | |
| | | Calibration accuracy (humidity transmitter) N10: ±1% from 10% to 80% (25 to 35°C) with NIST certificate N20: ±2% from 0% to 90% (25 to 35°C) with NIST certificate S20: ±2% from 0% to 90% (25 to 35°C) | | |
| | | N10 | | |
| | | |
| | | |
| | | Temperature transmitter range | | |
| | | S | | |
| | | |
| | | | | | | | | | | | EN: | -20°F | to | 140°F | | | | S: | 0°F | to | 100°F | | | | A: | 20°F | to | 120°F | | | | BI: | 30°F | to | 130°F | | | | KK: | 30°F | to | 180°F | | | | N: | 32°F | to | 122°F | | | | H: | 40°F | to | 90°F | | | | | | | | | | | |
| | | | |
| | | 3 | | |
| | | |
| | | |
| | | More temperature range codes on page 5-16 or www.minco.com/rangecode/ | | |
| | | |
| | | Sensing element cover (omitted on "S" space mount models) T0= Sintered stainless steel; pressed on cover T1 = Sintered stainless steel; screw on cover T2= Slotted stainless steel; screw on cover (NA on "O" outside air models) | | |
| | | T1 | | |
| | | |
| | | |
| | | To order enclosure D, O, S or W, stop here. To order enclosure R (remote probe), add: | | |
| | | |
| | | Probe mounting location A = Side mounting B = Bottom mounting | | |
| | | A | | |
| | | |
| | | |
| | | |
| | | Remote probe cable length (in inches) 48" and 96" are standard lengths | | |
| | | 48 | | |
| | | |
| | | |
| | | AH439R1N10ST1A48 = Sample part number | | |
| | | |
| | | Specifications subject to change | | |
| | | |
