| | | Flexible Thermal-Ribbon™ Pipe Sensors | | |
| | | |
| | | Overview Flexible Thermal-Ribbon™ sensors mount on the pipe surface so there's no expense of a pipefitter to drain, drill, and tap the pipe for a thermowell because there is no thermowell! When properly installed and insulated, the accuracy and response of a Thermal-Ribbon equals an immersed thermowell assembly. Options include stainless steel braid over leadwires to prevent abrasion damage and pressure-sensitive adhesive for easier mounting (smooth surfaces only). | | |
| | | THICKNESS: 0.045" (1.2 mm) over element <MODEL 5468PFI5 3.0" (76.2 mm) LONG | | |
| | | |
| | | Specifications Body material: Silicone rubber with polyimide backing. Temperature range: RTD: -62 to 200°C (-80 to 392°F). Thermistor: -45.5 to 135°C (-50 to 275°F). Leadwires: AWG 24, silicone rubber. Moisture resistance: Meets MIL-STD-202, Method 104, Test Condition B. | | |
| | | |
| | | |
| | | Model numbers | | |
| | | |
| | | | | | | | | | | | Element | TCR Q /Q/°C | Model | | | | RTDs | | | | | | Platinum | 100 Q ±0.1% at 0°C | 0.00391 | S464PB | | | | Platinum | 100 Q ±0.1% at 0°C | 0.00385 | S467PD | | | | (Meets EN60751, Class B) | | | | | | Platinum | 1000 Q ±0.1% at 0°C | 0.00385 | S468PF | | | | Nickel-iron | 1000 Q ±0.12% at 70°F | 0.00527 | S462FB | | | | Nickel-iron | 2000 Q ±0.12% at 70°F | 0.00527 | S463FC | | | | HW | 3000 Q at -30.2°C | 0.00262 | S100001PX | | | | | "25/ш25 | | | | | Thermistor | 2,252 Q ±1% at 25°C | 29.2 | TS436TA | | | | Thermistor | 10,000 Q ±1% at 25°C | 23.5 | TS437TB | | | | | | | | | | | |
| | | Note: Tape the Thermal-Ribbon in place beneath a layer of insulation. | | |
| | | |
| | | Mounting accessories: AC766 mounting kit Provides a pipe-mounted enclosure for transmitters and connections. Kit includes junction box, 5 ft. nylon strap, buckle, 4 wire nuts, and 6 ft. of #20 stretch tape. #20 stretch tape High temperature self-fusing silicone rubber tape for mounting Thermal-Ribbons to pipes. 1" wide rolls, 6 or 36 foot lengths. #6 RTV adhesive Room temperature vulcanizing adhesive for attaching Thermal-Ribbons to surfaces. 3 oz. (89 ml) tube. | | |
| | | |
| | | Specification and order options | | |
| | | |
| | | | | | | | | | S467PD | Model number from table | | | | Z | Number of leads: Y = 2 leads Z = 3 leads (RTD only) YS = 2 leads, stainless steel braid ZS = 3 leads, stainless steel braid (RTD only) | | | | 36 | Lead length in inches | | | | A | Adhesive backing: A = No adhesive B = Pressure-sensitive adhesive | | | | S467PDZ36A = Sample part number | | | | | | | | | |
| | | |
| | | |
| | | Specify and order products at: www.minco.com/sensors_config Specifications subject to change | | |
| | | |
| | | M | | |
| | | Sensors & Instruments Solutions Guide I www.mlnco.com Page 9-7 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | |
