Compact Wall-mount Full Size Wall-mount Dimensions:W3.12" (79 mm)
H2.09" (54 mm)
D1.80" (46 mm) Dimensions:W2.75" (70 mm)
H4.50" (114 mm)
D1.56" (40 mm) Specifications
Temperature range: -45.5 to 100°C (-50 to 212°F). Leadwires: Full size and compact: AWG 22, PTFE insulated, 4" (100 mm) long.Explosionproof and flush mount: AWG 2 6 , PTFE insulated,
Explosionproof Wall-mount Flush Wall-mount 6 " (150 mm) inside cover.
Dimensions:W1.60" (41 mm)
H5.55" (141 mm)
D2.05" (52 mm) Dimensions:W2.75" (70 mm)
H4.50" (114 mm)
D0.18" (5 mm) Moisture resistance: Meets MIL-STD-202, Method 104, TestCondition B.
Specification and order options:Room air sensors
S472PB Model number from table
Overview
Y Number of leads: Y=2 leadsZ=3 leads Minco’s room air sensors are available with a variety of enclo-sures that meet most standard and explosionproof HVAC/R
installations. The sensors can be match calibrated with a Minco
Temptran™ (
temperature transmitter) for increased accuracy
and reliability.Room air sensors are designed for wall mounting. Choose fromtwo
plastic enclosure styles with brushed aluminum faceplates
or a flushmount stainless steel model.The full-size enclosure and flushmount fit over standard junc-tion boxes. The full size enclosure has optional knockouts for
Wiremold raceway surface wiring. Just remove knockouts with
pliers. This enclosure may also include a 4-20 mA temperature
transmitter; specify model TT115 (or TT155 for high accuracy).The compact room air sensor mounts directly on drywall.
The explosionproof sensor housing is UL listed and CSAapproved for Class I, Groups C and D; Class II, Groups E, F, and G; and Class III. Download Application Aid #19 for more hazardous area information and the various standards and
agencies (including FM, CSA, CENELEC and ATEX) at
www.minco.com/sensoraid/. 4 Lead length in inches: (stocked only in 4") K0 Knockouts (full size only): K0=No knockoutsK1=Knockouts for wiremold raceway S472PBY4K0 = Sample part number
Notes: -For replacement cover only, order part AC692KO or AC692K1 for full size,
AC551 for compact.
- Room air sensors can use Temptran™ transmitter model TT115, which has
the same specifications as TT111. See page 5-2 for more information.
Please specify transmitters separately. Explosionproof wall-mount sensors and flushwall-mount sensors
S100147PD Model number from table Y Number of leads: Y=2 leadsZ=3 leads S100147PDY = Sample part number
Note: Transmitters must be installed in a separate enclosure when usedwith explosionproof wall-mount sensor. Element TCR Compactroom air sensors Full size
room air sensors Explosionproof
wall-mount sensors Flush mount
room air sensors Ω / Ω /°C RTDs Platinum100 Ω ±0.1% at 0°C 0.00391 S405PB S472PB Platinum100 Ω ±0.1% at 0°C(Meets EN60751, Class B) 0.00385 S448PD S473PD S100147PD S10145 6 PD Platinum1000 Ω ±0.1% at 0°C 0.00385 S449PF S474PF S100148PF S10145 6 PF Platinum1000 Ω ±0.1% at 0°C 0.00375 S483PW S489PW S101 6 08PW S10145 6 PW Nickel-iron1000 Ω ±0.12% at 70°F 0.00527 S403FB S470FB Nickel-iron2000 Ω ±0.12% at 70°F 0.00527 S404FC S471FC HW3000 Ω at -30.2°C 0.00262 S10000 6 4PX S10000 6 3PX
Thermistors R 25 ¼
R 125 Thermistor2,252 Ω ±1% at 25°C 29.2 TS42 6 TA TS424TA TS100149TA TS1017 6 9TA Thermistor10,000 Ω ±1% at 25°C 23.5 TS427TB TS425TB TS100150TB TS1017 6 9TB Page 9- 6
|
