Overview
Sense temperature of air streams in ducts and plenums. Sensorsinclude a
junction box with gasket to prevent leakage and
vibration noise.These point-sensing thermometers feature a fast-respondingaluminum sensing tip.Custom options include a NEMA 4 weatherproof connectionbox and an all stainless steel probe.Outside air sensors are designed to mount on conduit outside yourbuilding. They include an elbow type enclosure and sun shield.See page 5-2 for optional 4 to 20 mA
temperature transmitters.
Duct Point Sensor Enclosure:W2.12" (54 mm)
H4.00" (102 mm)
D1.75" (44 mm) Specifications
Probe Diameter:0.25" (6.4 mm)
0.188" (4.8 mm) at tip Outside Air Sensor Temperature range:
Dimensions:L5.6" (142 mm)
H1.6" (41 mm)
W1.3" (33 mm) Probe: -45.5 to 135°C (-50 to 275°F).
Gasket: 100°C (212°F) max. Leadwires: AWG 22, PTFE insulated, 4" (100 mm) long. Moisture resistance: Point sensors meet MIL-STD-202, Method 104, Test Condition B
Special options Specification and order options:Duct point sensors
Outside air sensors
•Weatherproof connection box•All stainless steel probe S450PD Model number from table Y Number of leads: Y = 2 leadsZ = 3 leads (RTD only)
Model numbers
12 Insertion depth in inches: Element TCR Duct point sensors Outside air sensors 1 inch = 25.4 mmStandard lengths: 3, 6, 12, 18"
Minimum: 3" Ω / Ω /°C RTDs S450PDY12 = Sample part number
HVAC SENSORS Platinum100 Ω ±0.1% at 0°C 0.00391 S408PB S414PB Platinum100 Ω ±0.1% at 0°C(Meets EN60751, Class B) 0.00385 S450PD S454PD Platinum1000 Ω ±0.1% at 0°C 0.00385 S451PF S455PF S414PB Model number from table Platinum1000 Ω ±0.1% at 0°C 0.00375 S484PW S48 6 PW Z Number of leads: Nickel-iron1000 Ω ±0.12% at 70°F 0.00527 S40 6 FB S412FB Y = 2 leadsZ = 3 leads (RTD only) Nickel-iron2000 Ω ±0.12% at 70°F 0.00527 S407FC S413FC HW3000 Ω at -30.2°C 0.00262 S1000 6 0PX S1000 6 2PX S414PBZ = Sample part number
Thermistors R 25 ¼
R 125 Thermistor2,252 Ω ±1% at 25°C 29.2 TS430TA TS428TA
Specify and order products at:
www.minco.com/sensors_config
Thermistor10,000 Ω ±1% at 25°C 23.5 TS431TB TS429TB
Specifications subject to change |
Page 9-5
