Chill-Out

TM

Combination Sensor

Bendable Aluminum Chill-Out Sensor installation example Ultra Flexible Brass Armor
Two sensors in one easily installed package: a solid state lowtemperature cut-out ("Freeze Stat") and an averaging resistancetemperature sensor.
Digital alarm signal to RTU, PLC or an electronic control; 24VAC-powered.
Solid state design and rugged 3/8 " diameter tubing eliminate concerns of gas leaks or kinking the capillary during installation.
Mount in any direction
horizontal installation is not required.
Easily formed aluminum or ultra flexible brass armor sensor case.

Specification and order options Overview


Relay and control circuitry self contained in rugged housing. Mounts on either side of enclosure with a locknut (included). AS103759 Model number PF Element Type: •
Failure detection feature
relay changes state if power is lost PF = 1000 Ω RTD (0.00385 Platinum) •
4 to 20 mA temperature loop output available with optional Temptran 38 Switching Temperature: 38
° FSpecify 30 to 44°F
(ordered separately
see Section 5 for more informa-tion) N Relay reset option: N = Non-latching (auto reset) L = Latching (manual reset) E = Latching (panel mounted reset)

Specifications

Switching temperature: 38°F factory pre-set, user adjustable from30°F to 44°F. Note: option ‘E’requires enclosure ‘L’ 10 Case length: 10 feet
Accuracy: ±0.9°F (±0.5°C) typical. A Case type:
Power requirement: 24V AC or DC. A = Aluminum B = Brass
Relay contact: User specified Standard relay, SPDT (2" x 4" utility box)0.3 A at 125 VAC, Max. Voltage 125 VAC, or1A at 30 VDC, Max. Voltage 110 VDCOptional power relay, DPST (4" x 4" utility box)25 A at 277 VAC25 A at 120 VAC1 HP at 120 VAC2 HP at 277 VAC 1 Relay Rating: 1 = 0.3A 2 = 25A, VAC powered controller/coil 3 = 25A, VDC powered controller/coil
Note: option 2 or 3 requires enclosure ‘L’ S Enclosure: N = No enclosure S = Standard utility box (2”x 4”) L = Large utility box (4”x 4”) W = Weatherproof utility box (2”x 4”)
Sensor case length: 10 feet standard, lengths up to 50 feet available by special order. AS103759PF38N10A1S = Sample part number
Connection: AWG 18 leadwires.

Order Replacement Relays

Model number External Relay AC103779 25A 24VAC Coil AC103780 25A 24VDC Coil
