| | | Machinery Protection Products | | |
| | | |
| | | End turn RTD | | |
| | | CT224 12-channel temperature alarm/monitor The CT224 consists of a 12-Channel Temperature monitor and MincoSoft™ CT224 Software. It is the next generation in temperature monitoring equipment from Minco designed to meet the needs of electric machinery protection. The 12-channel scanning capability, standard RS485/RS232 interface and Windows-compatible software utility for system configuration and data logging provide overtemperature and undertemperature protection and critical feedback to safeguard expensive machinery. • UL and cUL recognized to help meet regulatory compliance • Mix and match sensor input types for freedom to adapt to pre-installed bearing and apparatus sensors • Ability to monitor 12 inputs allows you to monitor stator sensors from two motors See page 5-24 for details. | | |
| | | |
| | | Model S3238Thermal-Ribbon is designed to sense stator temperatures in motors and generators. With an alternative installation method to the "stick-type" sensors in this section, S3238 is used on the end turns of stator windings and provides an easy way to add overtemperature protection when the stator is not being rewound. | | |
| | | |
| | | See page 10-5 for details. | | |
| | | |
| | | |
| | | CT15 temperature alarm | | • Flexible silicone rubber insulation • Mount on windings or housings to prevent moisture buildup • 2.5 to 10 watts per square inch at 120 or 240 volts • Variety of sizes to 60" (1.5 m) • UL component recognition • Available from stock | | |
| | | |
| | | Alarm shuts down motor on over-temperature to prevent catastrophic failure Monitors single 100 Q platinum RTD (PD or PE) 1 or 2 relays with independent trip points for warning and shutdown Microprocessor-based Front panel programmable with four security levels 100 to 240 VAC supply power | | |
| | | |
| | | |
| | | Compact DIN case with water resistant front panel | | |
| | | |
| | | See pages 5-26 for details. | | Go to www.minco.com/heater/for more information. | | |
| | | |
| | | |
| | | Specifications subject to change | | |
| | | |
| | | Access: Minco Sales and Support | | |
| | | Americas: 763.571.3121 | Europe: (33) 5 61 03 24 01 | Asia Pacific: (65) 6511 3388 | | |
| | | Page 8-8 | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
