| | | | | | | | | | | | | | | | | | | | | | | | | | | | Class F (155°C) RTDs | | | | | | | | | | | | | | | | | | | | Element | Model thickness: | | | | 0.030"" (.76mm) | 0.050"" (1.3mm) | 0.078"" (2.0mm) | 0.125" (3.2mm) | | | | Platinum (0.00392 TCR) 100 Q ±0.5% at 0°C | S1320PA1 | S7682PA | S,,PA | S8015PA | | | | Platinum (0.00385 TCR) 100 Q ±0.12% at 0°C (Meets EN60751, Class B) | S8009PD, | S8013PD | S8011PD | S8015PD | | | | Platinum (0.00385 TCR) 100 Q ±0.5% at 0°C | S8009PE1 | S8013PE | S8011PE | S8015PE | | | | Copper (0.00427 TCR) 10 Q ±0.2% at 25°C | S1120CA1 | S23CA | S3CA | S8015CA | | | | Nickel (0.00672 TCR) 120 Q ±0.5% at 0°C | S1140NA1 | S24NA | S4NA | S8015NA | | | | | | | | | | | | | | | | | | | | Specification and order options | | | | | | Class H (180°C) RTDs | | | | | | | | | | | | | | | | | | | | | S3CA | Model number from table | | | | 110 | Body length: Specify in 0.1" increments (Example: 110 = 11.0 inches) | | | | T | Leadwire insulation: T = PTFE K = Polyimide | | | | 344 | Body width: Specify in 0.001" increments (Example: 344 = 0.344 inches) Minimum body widths: 58015, 2 or3-lead: 320 S8015,4-lead:420 58016, 2 or3-lead: 320 S8016, 4-lead: 420 S100305: 310 S100415: 310 All other 4-lead models: 320 | | | | Z | Number of leads: Y = 2 leads (PA, PE, NAonly) Z = 3 leads X = 4 leads | | | | 36 | Lead length in inches | | | | S3CA110T344Z36 = Sample part number | | | | | | | | | | | | | | | | | | | | | | | Element | Model thickness: | | | | 0.030"" (.76mm) | 0.050"" (1.3mm) | 0.078" (2.0mm) | 0.125" (3.2mm) | | | | Platinum (0.00392 TCR) 100 Q ±0.5% at 0°C | S,420PA, | S7401PA | S,3PA | S8016PA | | | | Platinum (0.00385 TCR) 100 Q ±0.12% at 0°C (Meets EN60751, Class B) | S8010PD1 S100305PD2 S100415PD3 | S8014PD | S11016PD | S8016PD | | | | Platinum (0.00385 TCR) 100 Q ±0.5% at 0°C | S80,0PE, | S80,4PE | S80,2PE | S8016PE | | | | Copper (0.00427 TCR) 10 Q ±0.2% at 25°C | S,220CA, | S7401CA | S18CA | S8016CA | | | | Nickel (0.00672 TCR) 120 Q ±0.5% at 0°C | S,240NA, | S7401NA | S15NA | S8016NA | | | | | | | | | | | | | | | | | | | | Notes: 1 Leadwires: AWG 30; lead bulge: 0.045" thick, extending into the body a maximum of 0.62". 2 Leadwires: AWG 18; lead bulge: 0.110" thick, extending into the body a maximum of 1.75". 3 Leadwires: AWG 30 with PTFEjacket overall; lead bulge: 0.110" thick, extending into the bodya maximum of1.75". | | | | | | | | | | Specify and order products at: www.minco.com/sensors_config | | | | | | | | | | | | | | Specifications subject to change | | | | | | | | | | Page 8-5 | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
