| | | | | | | | | | | | | | | | | | | | | | | | | Economy Sensors | | | | | | | | | | | | | | | | | | | | | | | Dimensions | Temperature range | Element options | Case material | Leadwire | Model | | | | | 2 leads: .050" x .065" x .035" thick (1.3 x 1.7 x.9 mm) Thin-Film with insulated leads | -50 to 150°Ca (-58 to 302°F) | PD, PF | Ceramic | 2 leads: AWG 32 solid enamel insulated | S102404 | | | | | 3 leads: .063" x .079" x .035" thick (1.6x2x.9 mm) Thin-Film with insulated leads | 3 leads: AWG 34, solid enamel insulated | | | | -- | 0.125" x.90" (0 3.2 x22.9 mm) | -50 to 260°C (-58 to 500°F) | PD, PF, PW | Stainless steel | AWG 24, PTFE insulated | S102409 | | | | -—1II ■ 1 | 0.125" x.90" (0 3.2 x 22.9 mm) | -50 to 155°C (-58 to 311°F) | PD PF | Stainless steel | AWG 30, PTFE insulated | S102737 | | | | | 0.140" x.40" (0 3.6 x 10.2 mm) | -70 to 500°C (-94 to 932°F) | PD, PF, PW | Ceramic | AWG 27, solid glass insulated nickel | S102410 | | | | | 0 .188" x .90" (0 4.8 x22.9 mm) | -50 to 150°C (-58 to 302°F) | PD, PF, PW | Silicone rubber | AWG 24, silicone rubber insulated | S102406 | | | | | 0 .188" x 1.25" (0 4.8 x 31.8 mm) | -50 to 230°C (-58 to 446°F) | PD, PF, PW | PTFE | AWG 24, PTFE with PTFEjacket | S102405 | | | | | 0 .188" x 1.25" (0 4.8 x 31.8 mm) | -50 to 260°C (-58 to 500°F) | PD, PF, PW, NA | Aluminum | AWG 22, PTFE insulated | S102407 | | | | | 0 .188" x 2.38" (0 4.8 x 60.5 mm) | -70 to 550°C (-94 to 1022°F) | PD, PF, PW | Stainless steel | AWG 22, glass braid insulated | S102408 | | | | | | | | | | | | | | | | | | | | | | Specification and order options | | | | | | Overview Economy sensors are designed to be a component of your final assembly. With insulated leads preattached and strain relieved, final construction is easy and reliable. • Insulated leads of variable length, installed and strain relieved • Wide temperature range • Configurations to fit most applications • Standard 100 Q platinum, 1000 Q platinum and 120 Q nickel elements Specifications Insulation resistance: 10 megohms minimum at 100 VDC, leads to case. Vibration: Withstands 10 to 2000 Hz at 20 G's minimum per MIL-STD-202. Method 204, test condition D. | | | | | | | | | | | | | | | | | S102408 | Model number from table | | | | PD | Element code from table | | | | 3 | Number of leads: 2 leads (not recommended for PD models) or 3 leads (only option for S102410PD) | | | | G | Leadwire covering: E = Enamel (S102404) G = Glass (S102408 and S102410) R = Silicone rubber (S102406) T= PTFE (S102405, S102407, S102409, S102737) | | | | 40 | Leadwire length in inches: 40" (1000 mm) standard | | | | S102408PD3G40 = Sample part number | | | | | | | | | | | | | | | | | Specify and order products at: www.minco.com/sensors_config | | | | | | | | | | | | | | | | | | | | | | Element specifications* | Code | | | | Platinum (0.00385 TCR) | 100 Q ±0.12% at 0°C | | | | | (EN60751, Class B) | | PD | | | | Platinum (0.00385 TCR) | 1000 Q ±0.12% at 0°C | PF | | | | Platinum (0.00375 TCR) | 1000 Q ±0.12% at 0°C | PW | | | | Nickel (0.00672 TCR) | 120 Q ±0.50% at 0°C | NA | | | | | | | | | | | | | | | | | | *See descriptions for element options on each model. | | | | | | | | | | Specifications subject to change | | | | | | | | | | Sensors & Instruments Solutions Guide I www.minco.com Page 7-7 | | | | | | | | | | | | | | | | | | | | | | | | |
|
