| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | Dimensions WxLx T (max.) | Temperature range | Element options | Case material | Leadwire | Model | | | | ÊÊ3Ê | 0.50 x 1.00x0.188" (12.7x25.4x4.8 mm) with 0.161" (4.1 mm) diameter hole | -70 to 500°C (-94 to 932°F) | PD, PF, PW | Stainless steel | AWG 22, Mica-glass insulated | S101730 | | | | | 0.29 x 1.25x0.188" (7.4 x31.8 x4.8 mm) with 0.161" (4.1 mm) hole | -70 to 500°C (-94 to 932°F) | PD, PF, PW | Stainless steel | AWG 22, Mica-glass insulated | S101731 | | | | - | 0.265" (6.7 mm) ID ring lug | -50 to 260°C (-58 to 500°F) | PD, PE, PF, NB | Nickel plated copper | 2 lead: AWG 24, 3 lead: AWG 26, PTFE insulated | S101732 | | | | --rj | 0.50x0.375 x 0.188" (12.7 x 9.5 x 4.8 mm) with 0.166" (4.2 mm) hole | -50 to 260°C (-58 to 500°F) | PD, PE, PF, NB | Stainless steel | 2 lead: AWG 24, 3 lead: AWG 26, PTFE insulated with SS braid cover | S101733 | | | | | 1/4-20x3/8" long thread with V hex head | -50 to 260°C (-58 to 500°F) | PD, PE, PF, NB | Stainless steel | S101734 | | | | M6 x 1 thread, 10 mm long, with 10 mm hex | S101797 | | | | -HB | 0.51 x 1.97x0.079" (13 x 50 x 2 mm) with 0 0.130" (3.3 mm) holes spaced 1.47" (37.3 mm) apart | -50 to 180°C (-58 to 356°F) | PD, PF, PW, PS, NB, NA, NJ | High temperature epoxy glass | AWG 22, PTFE insulated, SS braid option | S100722 | | | | | | | | | | | | | | | | | | | | | | Insulation resistance: 10 megohms minimum at 100 VDC, leads to case. Vibration: Withstands 10 to 2000 Hz at 20G's minimum per MIL-STD-202. Method 204, test condition D. | | | | | | Overview Bolt-on temperature sensors are designed for easy installation in industrial and commercial environments. The sensors can be mounted on machines, against process pipes, or embedded directly into a machined part. Threaded fasteners install in seconds and can be easily removed for installation at another location. These sensors are ideal for process control measurements, test and verification of existing systems, and retrofitting existing machines. Standard designs allow prototyping without high setup costs, while significant discounts are available for large quantities. Standard platinum and nickel RTD elements provide stable and reliable output compatible with most control and monitoring systems. Physically interchangeable designs allow you to easily customize your installation to different | | | | | | | | | | | | | | | | | | Element specifications* | Code | | | | Platinum (0.00385 TCR) | 100 Q ±0.12% at 0°C | | | | | (EN60751, Class B) | | PD | | | | Platinum (0.00385 TCR) | 100 Q ±0.36% at 0°C | PE | | | | Platinum (0.00385 TCR) | 1000 Q ±0.12% at 0°C | PF | | | | Platinum (0.00375 TCR) | 1000 Q ±0.12% at 0°C | PW | | | | Platinum (0.00385 TCR) | 10000 Q ±0.12% at 0°C | PS | | | | Nickel 0.00618 TCR) | 100 Q ±0.22% at 0°C | MR | | | | (DIN43760 NI100, Class B) | | | | | | Nickel (0.00672 TCR) | 120 Q ±0.50% at 0°C | NA | | | | Nickel (0.00618 TCR) | 1000 Q ±0.22% at 0°C | NJ | | | | | | | | | | | | | | | | | | *See descriptions for element options on each model. Specification and order options | | | | | | instrumentation. Minco can also provide custom RTD, thermistor or thermocouple elements in these packages, | | | | | | | | | | | | | | | | | S101732 | Model number from table | | | | PD | Element code from table | | | | 3 | Number of leads: 2or3: 2 leads not recommended for PD models | | | | S | Leadwire covering: G = Mica-glass (S101730and S101731) T = PTFE (S100722, S101732, S101733, S101734,and S101797) S = Stainless steel braid over PTFE insulated leads (S100722, S101732, S101733, S101734,and S101797) | | | | 40 | Leadwire length in inches: 40" (1000 mm) standard | | | | S101732PD3S40 = Sample part number | | | | | | | | | | | | | or specialized case designs to meet your application needs. • Removable and reusable • Wide temperature range • Configurations to fit most applications • Standard 100 Q platinum, 1000 Q platinum and 100 Q nickel elements Specifications Time constant: Less than 10 seconds in moving water. | | | | | | | | | | | | | | Page 7-6 ACCÖSSI MllICO Americas: 763.571.3121 | Europe: (33) 5 61 03 24 01 | Asia Pacific: (65) 6511 3388 Sales and Support | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
