RTD Element	TCR Q/Q/°C	Case style A Case L: 0.250" (6.4 mm) Case 0:0.275" (7.0 mm)		Case style B Case L: 0.250" (6.4 mm) Case 0: 0.188" (4.8 mm) Flange 0: 0.250" (6.4 mm) —«-a		Case style C Case L: 0.300" (7.6 mm) Case 0:0.125" (3.2 mm) "--0—		Short case style B Case L: .188" (4.8 mm) Case 0: .188" (4.8 mm) Flange 0: 0.250" (6.4 mm)
RTD Element	TCR Q/Q/°C	Single	Dual	Single	Dual	Single	Dual	Single	Dual
Platinum, 100 Q ±0.36% at 0°C	.00392	S102617PA	S102617PAPA	S102618PA	S102618PAPA	S102619PA	S102619PAPA	S102662PA	S102662PAPA
Platinum, 100 Q ±0.12% at 0°C (Meets EN60751, Class B)	.00385	S102617PD	S102617PDPD	S102618PD	S102618PDPD	S102619PD	S102619PDPD	S102662PD	S102662PDPD
Platinum, 100 Q ±0.36% at 0°C	.00385	S102617PE	S102617PEPE	S102618PE	S102618PEPE	S102619PE	S102619PEPE	S102662PE	S102662PEPE
Platinum, 1000 Q ±0.12% at 0°C	.00385	S102617PF	S102617PFPF	S102618PF	S102618PFPF	S102619PF	S102619PFPF	S102662PF	S102662PFPF
Copper, 10 Q ±0.2% at 25°C	.00427	S102617CA	S102617CACA	S102618CA		S102619CA		S102662CA
Nickel, 120 Q ±0.5% at 0°C	.00672	S102617NA	S102617NANA	S102618NA	S102618NANA	S102619NA		S102662NA	S102662NANA


Thermocouple Junction Type	Case style A Case L: 0.250" (6.4 mm) Case 0: 0.275" (7.0 mm)		Case style B Case L: 0.250" (6.4 mm) Case 0: 0.188" (4.8 mm) Flange 0: 0.250" (6.4 mm)		Case style C Case L: 0.300" (7.6 mm) Case 0: 0.125" (3.2 mm) — -0—		Short case style B Case L: .188" (4.8 mm) Case 0: .188" (4.8 mm) Flange 0: 0.250" (6.4 mm) ^-—/>-g
Thermocouple Junction Type	Single	Dual	Single	Dual	Single	Dual	Single	Dual
E = Chromel-Constantan	TC102620E	TC102620EE	TC102621E	TC102621EE	TC102622E	TC102622EE	TC102663E	TC102663EE
J = Iron-Constantan	TC102620J	TC102620JJ	TC102621J	TC102621JJ	TC102622J	TC102622JJ	TC102663J	TC102663JJ
K = Chromel-Alumel	TC102620K	TC102620KK	TC102621K	TC102621KK	TC102622K	TC102622KK	TC102663K	TC102663KK
T = Copper-Constantan	TC102620T	TC102620TT	TC102621T	TC102621TT	TC102622T	TC102622TT	TC102663T	TC102663TT

Stop Oil Seepage!

Feedthroughs provide an oil tight industrial seal where a cable exits a machine housing. The stainless steel tube is epoxy filled and each wire is sealed to the individual conductor. This prevents wicking of oil inside the wires as well as leakage around the wire insulation. Pressure rating to 25 psi (1.7 bar.) See page 4-11 for details.

Leadwire and cable seal models FG1015 and FG3015 seal RTD or thermocouple leadwires where they exit oil-filled bearing housings of rotating equipment. Both versions include a grommet that provides the seal and allows adjustment of the wire or cable position. See page 4-12 for details.

Elastomer rubber-filled cable model AC100324 is a sensor cable with elastomer fill between the wires, stainless steel braid, and outer jacket. This fill can extend along the entire length of the cable, or a specified portion. The outside of the cable can be sealed with an FG1015 or FG3015 fitting. See page 4-13 for details.

Minco Application Aid #27 provides more information on the problems of oil seepage and various solutions. Download AA#27 at www.minco.com/sensoraid/

Specifications subject to change

Sensors & Instruments Solutions Guide I www.minco.com Page 7-5
