Non-sparking Embedment Sensors

Overview

• Non-sparking embedment sensors for monitoring the temperature of thrust bearings

• Four case styles offer a variety of installation options

• Certified for use in Zone 2, Group IIC hazardous areas

Specifications

Temperature range: -50 to 200°C (-58 to 392°F), reducing to 125°C (257°F) when elastomer filled cable is ordered.

Case: Tin plated copper alloy.

Babbitt tip: Factory applied babbitt tip, available on case style A, B, and short style B, reduces the danger of overheating the sensor when installed in babbitt layer.

Leads:

RTD: stranded copper with PTFE insulation.

Stainless steel braid, FEP over PTFE and FEP over stainless

steel braid with elastomer fill are optional. Thermocouple: stranded, PTFE insulated, twisted pairs.

Stainless steel braid, FEP over PTFE and FEP over stainless

steel braid with elastomer fill are optional.

Specification and order options:

RTD non-sparking embedment sensors


	S102617PD	Model number from next page
	3	Number of leads per sensing element (2,3 or 4): CA or PD require 3 or 4 leads per element 4 leads available on all single elements and dual S102618 only
	F	Covering over leadwires: T = PTFE only S = SS braid over PTFE insulated leads F = FEP over PTFE insulated leads E = FEP over SS braid with elastomer fill (max. fill length 144")
	48	Lead length in inches
	(Stop here for case style C; no babbitt option) \|
	B0	Optional babbitt tip: B0 = No babbitt metal B1 = Babbitt metal applied
	S102617PD3F48B0 = Sample part number \|
	Thermocouple non-sparking embedment sensors
	TC102621E	Model number from next page
	U	Junction grounding: G = Grounded U = Ungrounded
	48	Lead length in inches
	F	Covering over leadwires: T = PTFE only S = SS braid over PTFE insulated leads F = FEP over PTFE insulated leads E = FEP over SS braid with elastomer fill (max. fill length 44")
	(Stop here for case style C; no babbitt option)
	B0	Optional babbitt tip: B0 = No babbitt metal B1 = Babbitt metal applied

Leadwire size (AWG):


RTD
Case style	Number of leads
Case style	2	3	4	6	8
A	24	24	24	24
B	24	24	28	28	28
C	24	26	30	30
Short B	24	26	28	30
Thermocouple
All cases	24	24

Time constant: 3.0 seconds (case style A), typical in moving water.

Insulation resistance: 10 megohms minimum at 100 VDC, leads to case.

Specify and order products at: www.minco.com/sensors_config

TC102621EU48FB0 = Sample part number

Specifications subject to change
