| Overview Install directly into process lines for fast response. Cases, made of polished 316 stainless steel, are free of cracks and crevices that might shelter bacteria. External cables will withstand wash-down; optional stainless steel armor prevents abrasion wear. Tri-clamp® caps are standard. Contact Minco for other styles. Note that clamp and gasket are not part of the assembly. Get more information on page 6-4. Specifications Sensing element: Platinum RTD, 100 Q ±0.1% at 0°C, TCR = 0.00385 Q/Q/°C (Meets EN60751, Class B). Temperature range: Probe: -100 to 200°C (-148 to 392°F). External leadwires:-100 to 121°C (-148 to 250°F). Material: 316 stainless steel. Finish: Standard: #4 finish per 3-A standard 74-02,32 microinches max. Pharmaceutical (optional): Polished to mirror finish and passivated. 10 microinches typical. Pressure rating: 500 psi (34.5 bar). Leadwires: AWG 22, polyimide insulation; optional stainless steel armor. Polyolefin shrink tubing wrap standard over either option. Time constant: 2 seconds. Self-heating: 50 mW/°C typical in moving water. Insulation resistance: Single element probes: 1000 megohms minimum at 500 VDC, leads to case. Dual element probes: 100 megohms minimum at 100 VDC, between elements and leads to case. |
