Standard Wire-wound Rubber Heaters
Minco has invested in the design time and fabrication toolingso you can jump immediately to your prototyping efforts. Thefollowing table outlines the benefits and specifications of previously designed Minco wire-wound rubber heaters. Minco's build-to-order turnaround time is typically 3 weeksdepending on quantity requirements. There is a limited availableinventory of a variety of part configurations which generallyallows us to meet your immediate delivery needs.Contact Access: Minco Sales and Support to discuss mix andmatching heater sizes and resistance values to help satisfy performance and leadtime demands.
IntroductionDesignGuide Specification options
HR6600 Model number R576 Heater resistance in ohms L12 Lead length in inches
12" (305 mm) is standard
A Heater backing
A = No backing-45 to 220°CB = #12 PSA backing-45 to 177°C
D = Aluminum foil backing-45 to 220°C
E = Aluminum foil with Acrylic PSA-32 to 150°C
F = Aluminum foil with #12 PSA-45 to 204°C
P olyimideHeatersSiliconeRubberHeaters (foil)Standard HR6600R576L12A = Sample part number
120 volt heaters Size (in) Size (mm) 2.5 W/in² (0.39 W/cm²) 5 W/in² (0.7 8 W/cm²) 10 W/in² (1.55 W/cm²) 15 W/in² (2.33 W/cm²)
ModelNumber
X Y X Y WattsResistance WattsResistance WattsResistance WattsResistance 1 5 25 127 25 W576 Ω 50 W288 Ω 75 W192 Ω HR6600 1 6 25 152 30 W480 Ω 60 W240 Ω 90 W160 Ω HR6693 1 10 25 254 25 W576 Ω 50 W288 Ω 100 W144 Ω 150 W96.0 Ω HR6602 1 12 25 305 30 W480 Ω 60 W240 Ω 120 W120 Ω 180 W80.0 Ω HR6694
P olyimide& RubberRubberHeaters(wire-wound)Mica HeatersThermal-ClearHeatersAll- 1 15 25 381 38 W384 Ω 75 W192 Ω 150 W96.0 Ω 225 W64.0 Ω HR6604 1 20 25 508 50 W288 Ω 100 W144 Ω 200 W72.0 Ω 300 W48.0 Ω HR6606 1 24 25 610 60 W240 Ω 120 W120 Ω 240 W60.0 Ω 360 W40.0 Ω HR6696 1 25 25 635 63 W230 Ω 125 W115 Ω 250 W57.6 Ω 375 W38.4 Ω HR6608 1 30 25 762 75 W192 Ω 150 W96.0 Ω 300 W48.0 Ω 450 W32.0 Ω HR6610 1 35 25 889 88 W165 Ω 175 W82.3 Ω 350 W41.1 Ω 525 W27.4 Ω HR6612 1 40 25 1016 100 W144 Ω 200 W72.0 Ω 400 W36.0 Ω 600 W24.0 Ω HR6614 1 60 25 1524 150 W96.0 Ω 300 W48.0 Ω 600 W24.0 Ω 900 W16.0 Ω HR6616 1 70 25 1778 175 W82.3 Ω 350 W41.1 Ω 700 W20.6 Ω HR6618 2 5 51 127 25 W576 Ω 50 W288 Ω 100 W144 Ω 150 W96.0 Ω HR6619 2 10 51 254 50 W288 Ω 100 W144 Ω 200 W72.0 Ω 300 W48.0 Ω HR6621 2 15 51 381 75 W192 Ω 150 W96.0 Ω 300 W48.0 Ω 450 W32.0 Ω HR6623 2 20 51 508 100 W144 Ω 200 W72.0 Ω 400 W36.0 Ω 600 W24.0 Ω HR6625 2 24 51 610 120 W120 Ω 240 W60.0 Ω 480 W30.0 Ω 720 W20.0 Ω HR6698 2 25 51 635 125 W115 Ω 250 W57.6 Ω 500 W28.8 Ω 750 W19.2 Ω HR6627 2 30 51 762 150 W96.0 Ω 300 W48.0 Ω 600 W24.0 Ω 900 W16.0 Ω HR6629 2 35 51 889 175 W82.3 Ω 350 W41.1 Ω 700 W20.6 Ω 1050 W13.7 Ω HR6631 2 40 51 1016 200 W72.0 Ω 400 W36.0 Ω 800 W18.0 Ω 1200 W12.0 Ω HR6633 2 60 51 1524 300 W48.0 Ω 600 W24.0 Ω 1200 W12.0 Ω HR6635 2 70 51 1778 350 W41.1 Ω 700 W20.6 Ω 1400 W10.3 Ω HR6637
P 3 5 76 127 38 W384 Ω 75 W192 Ω 150 W96.0 Ω 225 W64.0 Ω HR6638
olyimideHeatersSensors,Controllers &AccessoriesReference 3 10 76 254 75 W192 Ω 150 W96.0 Ω 300 W48.0 Ω 450 W32.0 Ω HR6640 3 15 76 381 113 W128 Ω 225 W64.0 Ω 450 W32.0 Ω 675 W21.3 Ω HR6642 3 20 76 508 150 W96.0 Ω 300 W48.0 Ω 600 W24.0 Ω 900 W16.0 Ω HR6644 3 25 76 635 188 W76.8 Ω 375 W38.4 Ω 750 W19.2 Ω 1125 W12.8 Ω HR6646 3 30 76 762 225 W64.0 Ω 450 W32.0 Ω 900 W16.0 Ω 1350 W10.7 Ω HR6648 3 35 76 889 263 W54.9 Ω 525 W27.4 Ω 1050 W13.7 Ω 1575 W9.1 Ω HR6650* 3 40 76 1016 300 W48.0 Ω 600 W24.0 Ω 1200 W12.0 Ω HR6652 3 60 76 1524 450 W32.0 Ω 900 W16.0 Ω HR6654 3 70 76 1778 525 W27.4 Ω 1050 W13.7 Ω HR6655 4 5 102 127 50 W288 Ω 100 W144 Ω 200 W72.0 Ω 300 W48.0 Ω HR6656 4 10 102 254 100 W144 Ω 200 W72.0 Ω 400 W36.0 Ω 600 W24.0 Ω HR6658 4 15 102 381 150 W96.0 Ω 300 W48.0 Ω 600 W24.0 Ω 900 W16.0 Ω HR6660 4 20 102 508 200 W72.0 Ω 400 W36.0 Ω 800 W18.0 Ω 1200 W12.0 Ω HR6662 4 25 102 635 250 W57.6 Ω 500 W28.8 Ω 1000 W14.4 Ω 1500 W9.6 Ω HR6664* 4 30 102 762 300 W48.0 Ω 600 W24.0 Ω 1200 W12.0 Ω HR6666 *AWG 18 le a d s (AWG 20 i s s t a nd a rd) Specifications subject to change
