| | | Standard Polyimide and Rubber Heaters | | |
| | | |
| | | Minco has invested in the design time and fabrication tooling so you can jump immediately to your prototyping efforts. The following table outlines the specifications of previously designed polyimide and silicone rubber Thermofoil™ heaters. Minco's build-to-order turnaround time is typically 3 weeks depending on quantity requirements. There is a limited available inventory of a variety of part configurations which generally allows us to meet your immediate delivery needs. Contact Access: Minco Sales and Support to discuss mix and matching heater sizes and resistance values to help satisfy performance and lead time demands. | | Specification options Technical Specifications on pages 16 (polyimide) & 20 (rubber). | | |
| | | |
| | | Insulation: HK = Polyimide HR = Silicone rubber | | |
| | | HK | | |
| | | |
| | | |
| | | Model number from tables on following pages | | |
| | | 5200 | | |
| | | |
| | | |
| | | Heater resistance in ohms | | |
| | | R17.4 | | |
| | | |
| | | Lead length in inches 12" (305 mm) is standard Contact Minco for other lengths | | |
| | | L12 | | |
| | | |
| | | |
| | | Heater backing option (see page 8) | | |
| | | A | | |
| | | |
| | | |
| | | |
| | | Type (configuration) | | |
| | | HK -200 to 200°C -32 to 100°C -200 to 150°C -32 to 150°C -73 to 150°C | | HR -45 -45 -45 -32 -45 | | |
| | | |
| | | A = No adhesive B = PSA backing D = Foil backing E = Foil/Acrylic PSA F = Foil/#12 PSA | | |
| | | to 235°C to 177°C to 235°C to 150°C to 204°C | | |
| | | |
| | | |
| | | U | | |
| | | U = Marked for UL component recognition: Omit for no UL marking (lower cost) UL limits: 220°C for rubber heaters | | |
| | | »p t CT 3 Q. | | |
| | | |
| | | |
| | | |
| | | UNHEATED AWG 30: 0.4 AWG 26: 0.4 | | AB: 0" long X 0.25" wide (10.2 X 6.4 mm) 0" X 0.40" (10.2 X 10.2 mm) | | |
| | | ■ V | | |
| | | HK5200R17.4L12AU = Sample part number | | |
| | | |
| | | |
| | | |
| | | Temperature sensitive elements Heaterstats™ (page 44) require temperature sensitive heating elements, such as those found in the "NiFe" and "Ni"columns. Their resistance increases with temperature. The resistances listed are measured at 0°C (32°F). | | |
| | | SHE | | |
| | | 21 | | |
| | | |
| | | |
| | | Types 21,30, and 31 have lead connections on an external tab. The tab produces negligible heat and, in most cases, need not be adhered to the heat sink. On type 21 heaters that are 0.25" (6.4 mm) wide, the tab is the same width as the heated area. | | |
| | | |
| | | |
| | | How to use the table of Standard Polyimide & Silicone Rubber Heaters Element resistance Overall heater size in options in ohms. Select Available heater inches. Listed in resistance to produce Effective heating area. insulation options ascending order, first Heater type desired wattage with Use this value for for this model. by dimension X, then Y. (lead exit available voltage calculating watt K=Polyimide Round heaters are last. configuration). (see Ohm's law). density R=rubber | | |
| | | |
| | | | | | | | | | | | | | | | | | | Size (in) | Size (mm) | Type | Resistance options- ohms* | | Effective area | Lead | Insu- | Model | | | | XY | XY | | R(0°C) [May be used with Heaterstat] — | NiFe Ni | in2 (cm2) | AWG | lation | number | | | | 0.40 | 2.60 | 10.2 | 66.0 | 1 1 | 123 62.5 37.8 18.2 | 19.1 | 0.74 (4.77) | 30 | K, R | 5215 | | | | 0.41 | 4.80 | 10.4 | 121.9 | 6 6 | 100 50.1 30.2 14.5 | 15.5 | 1.40 (9.03) | 26 | K, R | 5218 | | | | 0.41 | 8.30 | 10.4 | 210.8 | 5 5 | 61.9 31.1 18.8 9.1 6.2 4.3 | 9.6 | 2 50 (16.13) | 26 | K, R | 5219 | | | | | | | | | | | | | | | | | | |
| | | |
| | | Leadwire size. Maximum current capacities are listed on pages 17 and 20. | | Base model number | | |
| | | Temperature sensitive element resistance options (at 0°C) for use with Minco Heaterstat. Rubber (HR) models are not available with NiFe element. *Resistance tolerance is ±10% or ±0.5, whichever is greater Rubber (HR) models not available with NiFe element | | |
| | | Overall heater size in millimeters. Listed in ascending order, first by dimension X, then Y. | | |
| | | |
| | | |
| | | |
| | | |
