® All-In-One MIG Buyer's Guide Everything You Need... Everywhere You Need It.

Open the catalog to page 1

Sept. 2010 Everything You Need... Everywhere You Need It A Complete Line Of All-In-One MIG Welders Fully Loaded Features For Best Value How The Original All-In-One MIG Welder Got Its Start Just Ask, We'll Answer Designed For The Hobbyist, Built For The Professional Product Selector Guide Product Highlights 4 5 5 5 6 8 1012 tmer. 3

Open the catalog to page 2

Everywhere You Need It. 4 Millermatic® Passport® Plus Millermatic® 350P Millermatic® 140 Auto-Set™ Millermatic® 180 Auto-Set™ Millermatic® 252 Millermatic® 212 Auto-Set™ Millermatic®211 Auto-Set™ w/MVP™

Open the catalog to page 3

a complte Line ut All-In-One MIG Welders Whether you need ultimate arc performance, power to weld thick metals, pulsed MIG to weld thin-gauge aluminum, the flexibility to go anywhere, or all of the above the Millermatic line from Miller provides you the optimal choice of all-in-one MIG welders. From farmers to metal fabricators, manufacturing plants to home mechanics and hobbyists, there's a Millermatic to fit your application and budget. This guide is to help you decide which machine is right for you and your applications, answer popular questions, and provide detailed descriptions of...

Open the catalog to page 4

Sometimes referred to as a wire welder, a MIG welder creates an arc between a continuously fed filler metal (consumable) electrode and the weldment. Some advantages of MIG welding are: • Welds light gauge material, including aluminum, or thick plates • Welds all common metals, including carbon steel, stainless steel, and aluminum • High-production welding speeds — MIG welding is up to four times faster with nearly double the metal deposition rate as the Stick welding process • Less smoke and no slag to chip off • An easy process to learn Can MIG Equipment Also Be Used For Flux Cored...

Open the catalog to page 5

Does Input Power (115 or 230 Volts) Make A Difference? Yes, because power in equals power out. A welder with 230 V/30 A of input can weld thicker metals than a 115 V/20 A welder. If you are unsure of what input power you have available, or think you may need both, look for a machine that can work off of either 115 or 230 V input power Miller offers two products for this, the Millermatic® Passport" Plus and the Millermatic® 211 Auto-Set" w/MVP". What Does Duty Cycle Mean? Duty cycle is the amount of time during a 10-minute period that a welder can operate at a given amperage without...

Open the catalog to page 6

with ultimate arc performance to give you the best all-in-one MIG welders in the industry. Auto-Set™ Available on Millermatic 140, 180, 211 and 212. The right setting automatically — • Set the wire diameter, a blue light shows that Auto-Set is activated • Dial in the thickness of what you’re welding • Start welding with the exact parameters you need! No more burn through and rework — Correct Auto-Set parameters make it easy to get quality welds, every time. Weld flexibility with infinite voltage control — You also have the flexibility to manually adjust weld parameters to the exact settings...

Open the catalog to page 7

Thermal overload protection Designed to protect your investment, every Millermatic is now equipped with built-in thermal overload protection. . . not that you'll need it. Set-up and opשration CD Miller makes it easy to get started. Every Millermatic comes standard with a CD that goes through the basics of how to set up and operate your machine to get optimal results. True Blue® 3-year warranty ח You should never have an issue with your Millermatic. . . but just in case, each welder is warranted for three years, parts and labor. Original main power rectified parts are warranted for five...

Open the catalog to page 8

10 200/230/460 VAC 300 A at 60% Duty Cycle, 1-Phase or 3-Phase Millermatic® 350P 115 VAC 110 A at 20% Duty Cycle Millermatic® Passport® Plus 208/230 VAC 160 A at 60% Duty Cycle 230 VAC 150 A at 30% Duty Cycle 115 VAC 90 A at 20% Duty Cycle 230 VAC 130 A at 30% Duty Cycle Millermatic® 180 Auto-Set™ MACHINE MATERIAL THICKNESS WELDED IN A SINGLE PASS Millermatic® 252 Millermatic® 212 Auto-Set™ Millermatic® 211 Auto-Set™ w/MVP™ 115 VAC 90 A at 20% Duty Cycle Millermatic® 140 Auto-Set™ 208/230 VAC or 230/460/575 VAC 200 A at 60% Duty Cycle Thin Gauge 3/16 in 1/4 in 230 VAC 150 A at 20% Duty...

Open the catalog to page 9

Auto-Set™ — the Auto-Set feature makes set up quick and easy. For more information on Auto-Set refer to page 8. Infinite voltage adjustment provides broader operating range with finer control than a tap machine. Smooth-Start provides smooth, spatter-free starts — no pop gun starts and no spatter to clean up. “Tip Saver” shuts down output when tip is shorted to the work. Extends contact tip life and protects internal components from damage. Heavy duty aluminum drive system. Uses 4 or 8 in (102 or 203 mm) spools. Welding Capability Not to scale. 12 Millermatic® 180 Auto-Set™ All the same...

Open the catalog to page 10

Millermatic® Passport® Plus Portability is #1 because not all jobs can come to you weighing in at 45 lb and running either 115 or 230 V the Passport Plus is great for steel, aluminum and stainless steel jobs you need to go to. Multi-Voltage Plug (MVPי) Miller's MVP allows connection to 115 or 230 V rceptacles without tools. Excellent arc characteristics! Unit offers positive arc starts and an extremely stable arc with minimal spatter on both mixed gases and straight CO2. Flexibility to use either external or internal gas cylinder. Self-contained gas cylinder provides 25 minutes of arc time...

Open the catalog to page 11

14 up quick and easy. For more information on Auto-Set refer to page 8. Infinite voltage adjustment provides broader operating range with finer control than a tap machine. Multi-Voltage Plug (MVP™) — Miller’s MVP allows connection to 115 or 230 V receptacles without tools. Smooth-Start provides smooth, spatter-free starts — no pop gun starts and no spatter to clean up. “Tip Saver” shuts down output when tip is shorted to the work. Extends contact tip life and protects internal components from damage. Welding Capability Not to scale. Recommended aluminum solution: Spoolmate 100 Series #300...
