RPS-40-5 Features Proximity Detection Proximity Detection Proximity detection is the detection of an object in a given range. The detection range of the RPS-40-5 is fixed at 0.5 - 5". Any object within the desired range is detected, while objects out of range are ignored (background suppression). The detect point is independent of size, material, and reflectivity. with background suppression (meaning any object within the range is detected, while objects out of the range are ignored). It cannot be affected by changes in target color or material. The RPS-40-5 is capable of detecting...

PART NUMBER RANGE OUTPUT Operational Range: 0.5 - 5" Power Input: 12 - 24VDC Reverse Polarity Protected Input Current: 20mA Typical Ambient Temperature: 0 - 50º C or 32 - 122º F Humidity: 0 - 95% Non-Condensing Housing: Valox housing with glass filled epoxy sensing face. Outputs: NPN Sinking 24V maximum / 100mA continuous PNP Sourcing 24V maximum / 100mA continuous Transducer Frequency: 400kHz Response Time: On - 10ms Off - 50ms Weight of Controller: 2 ounces Specifications: Fig. B Fig. A RPS-40-5 0.5 - 5" NPN and PNP Outputs Figure: A - Angle of Tilt B - Beam Spread C - Wiring Diagram D -...

• Adjustable Hysteresis • 105 - 130VAC or 20 - 30VDC Power • Isolated N.O. N.C. Solid State Relays • Limit Switch Style Housing • Adjustable Sensing Range • Broad Sensing Beam • Range 2 - 40", or 5 - 80" • LED Indicator RPS-150 Features The RPS-150 is a self-contained, wide beam angle ultrasonic sensor. The advantage of this sensor is that the target does not have to be at right angles with the sensor in order to be detected. A flat target can tilt up to 35 degrees and still be detected. For setup purposes an LED indicator is provided. When in the non-detect state the LED is Green and when...

Operational Range: Adjustable 2 - 40" Adjustable 5 - 80" Hysteresis: Adjustable 0.5 - 40" Adjustable 1 - 80" Power Input: 105 - 130VAC (AC Version) 20 - 30VDC (DC Version) Input Current: 15mA VAC or 35mA VDC Ambient Temperature: 0 - 60ºC or 32 - 140ºF Humidity: 0 - 95% Non-Condensing Transducer Housing:: Plastic Valox Limit Switch Style Outputs: 2 Solid State Relays N.O. N.C. Isolated 1500VRMS 2 - 130VAC or VDC 50mAAC or 100mADC Continuous Short Circuit Protected Transducer Frequency: 38.5kHz Response Time: 2 - 40" 5 - 80" On 60ms 120ms Off 60ms 120ms Weight: 9.5 ounces Fig. A...

• Adjustable Zero & Span • Broad Sensing Beam • Range 2 - 40", or 5 - 80" • LED Strength Indicator • Analog Current & Voltage Output • Selectable Inverted & Non-Inverted Outputs • Short Circuit & Reverse Polarity Protected • Limit Switch Style Housing RPS-150A Features 10" 24" Adjustable Adjustable Adjustable 2" 5" 40" 80" 0V 4mA 10V 20mA 0V 4mA 10V 20mA 10V 20mA 0V 4mA 2" 40" 12" 5" 80" 15" 40" Range 80" Range 40" Range 80" Range place, depending on how much reflected signal is coming back from the target. The frequency of operation is 38.5kHz. There are two ranges available in this model...

Operational Range: Adjustable 2 - 40" Adjustable 5 - 80" Power Input: 20 - 30VDC Reverse Polarity Protected Input Current: 50mADC Ambient Temperature: 0 - 60ºC or 32 - 140ºF Humidity: 0 - 95% Non-Condensing Transducer Housing: Plastic Valox Limit Switch Style Outputs: Current Sourcing Analog Output 4 - 20mA Inverted & Non-Inverted Load 0 ohms to 500 ohms maximum Analog Voltage Output 0 - 10V Inverted & Non-Inverted Load 500 ohms to infinity Short Circuit Protected Transducer Frequency: 38.5kHz Response Time: 2 - 40" 5" - 80" 22ms 52ms Weight: 9.5 ounces Fig. A Specifications: Fig. B SENSOR...

RPS-400-6P Features Proximity Detection Adjustable Proximity Detection Proximity detection is the detection of an object in a given range. The detection range of the RPS-400-6P is controlled by the "Range Control" potentiometer located on the side of the sensor. Any object within the desired range is detected, while objects out of range are ignored (background suppression). The detect point is independent of size, material, and reflectivity. ing range with background suppression (meaning any object within the desired range is detected, while objects out of the desired range are ignored). It...

PART NUMBER RANGE OUTPUT Operational Range: Adjustable 2 - 6" Power Input: 20 - 30VDC Reverse Polarity Protected Input Current: 25mA Typical Ambient Temperature: -18 - 60º C or 0º - 140º F Humidity: 0 - 95% Non-Condensing RPS-400-6 Housing Valox case with glass filled epoxy sensing face. Output: NPN Open collector transistor. 30V max/50mA continuous Transducer Frequency: 400kHz Response Time: 0.2ms min / 2.1ms max Weight of Controller: 2 ounces Specifications: Fig. C Fig. D Fig. B Fig. A RPS-400-6P 2 - 6" NPN Open Collector Transistor ( 30V max/50mA continuous ) Figure: A - Angle of Tilt B...

RPS-400-30 Features The RPS-400-30 has a 22mm barrel housing, completely self-contained, 12 - 30VDC powered ultrasonic proximity sensor. A sealed transducer provides protection in environments where dirt and moisture are a problem. The sensor is constructed of Delrin plastic with a silicon rubber sensing face. This sensor is range or distance sensitive, enabling the sensor to detect objects only within the desired range, and reject objects outside the desired range. The RPS-400-30 is a solid state sensor and has an NPN open collector transistor output. For initial setup purposes, a built in...

Migatron Corp. PART NUMBER RANGE OUTPUT RPS-400-30 5 - 30" NPN Open Collector Output Resistor Chart Resistor Value 10k 22k 47k 68k 100k 150k 220k 330k Approx. Distance 5" 6" 7" 9" 11" 15" 20" 30" Figure: A- Angle of Tilt B- Beam Spread C- Wiring Diag..- Connect to NPN Output D- Wiring Diag..- Load and Range Control Pot E- Mounting Dimensions Fig. E Fig. D Sensor RED 12 - 30VDC WHT LOAD GROUND BLK GRN RED 12 - 30VDC WHT OUTPUT BLK GROUND GRN RANGE ADJ. Sensor NPN Transistor Output Fig. C 111mm 4.375" 22.2mm Thread Size Pg16 Operational Range: Adjustable 5 - 30" Power Input: 12 - 30VDC Input...
