MEN M-Module Mezzanine I/O
N 4 16-bit D/A converters
N Individual offset and output voltage range
N 100kHz update rate per channel
N 7µs acquisition/conversion time
N ±10V measuring range
N 2 DSPs, 32 MIPS each
N 160kB memory
N Optical isolationD/A Conversion M-Module
™ Characteristics
N Bump: 10g/16ms
N Resolution: 16 bits
N A08, D16, INTA, IDENT, TRIGI
N Vibration (sinusoidal): 2g/10..150Hz
N Conversion time: 7µs
Electrical Specifications
N Conformal coating on request
N Absolute accuracy: ±0.5%
N Isolation voltage:
Safety
N Differential accuracy: ±0.05%, no missing codes
N 500V DC between isolated side and digital side
N PCB manufactured with a flammability rating of 94V-0 by UL recognized manufacturers
Outputs
N Voltage between the connector shield and isolated ground is limited to 180V using a varistor; AC coupling between connector shield and isolated ground through 47nF
industrial capacitor EMC
N 4 analog outputs
N Tested according to EN 55022 (radio disturbance), IEC1000-4-2 (ESD) and IEC1000-4-4 (burst) with regard to CE conformity
N Current range: ±1mA
N Voltage range: ±10V
N Output accuracy depends on load resistance
N Output impedance: 0 Ohm
N Supply voltage/power consumption: +5V (4.85V..5.25V), 500mA
Miscellaneous
N Adjustable peak via 12-bit
DAC N MTBF: 151,000h @ 50°C (derived from MIL-HDBK-217F)
N Self-calibration (firmware)
N 6th-order output lowpass filter 15kHz
Mechanical Specifications
N 100kHz maximum output rate
N Dimensions: conforming to M-Module
™ Standard
Digital Signal Processing
N 2 processors ADSP 2181 (Analog Devices)
N Weight: 98g
N Data reduction by interpolation
Environmental Specifications
N 16k x 16 bits data buffer
N Temperature range (operation):
N 16k x 24 bits program memory
N 0..+60°C or -40..+85°C
N Programming via host interface
N Airflow: min. 10m³/h
N External or internal trigger (software-programmable)
N Temperature range (storage): -40..+85°C
N Relative humidity range (operation): max. 95% non-condensing
Peripheral Connections
N Via front panel on 4 shielded receptacle
connectors manufacturer N Relative humidity range (storage): max. 95% non-condensing
N Via carrier board (rear I/O)
N Altitude: -300m to + 3,000m
N Shock: 15g/11ms
M-Module Mezzanine I/O 92
