SC13C – 6U PowerPC

®

SBC with PMCs

PowerPC

MPC8245/300MHz

6U form factor

512MB DRAM, CompactFlash

® N

Graphics via PMC

Dual 10/100Mbit Fast Ethernet

4 COMs, USB, IDE, keyboard/mouse

2 PMC slots CPU

N IDE port for hard disk drives

Electrical Specifications

N PowerPC
® MPC8245, 300MHz
N Drive can be connected via ribbon cable or mounted directly on the CPU board using MEN adapter kit
N Supply voltage/power consumption:

Memory

N +5V (4.85V..5.25V), 1.65 A typ.
N Level 1 Cache integrated in MPC8245
N ±12V for industrial mezzanines only, tbd.
N Up to 512MB SDRAM system memory
N Keyboard/mouse
N MTBF: 63,000h @ 50°C (derived from MIL-HDBK-217F)
N 1 SO-DIMM slot, 100MHz memory bus frequ.
N PS/2 compatible
N Flash 2MB
N External adapters for line drivers required

Mechanical Specifications

N Serial EEPROM 2KB for factory settings
N USB port
N Dimensions: standard double Eurocard, 233.3mm x 160mm
N CompactFlash
® card interface for Flash ATA (true IDE) via on-board IDE
N External line drivers

Local PCI Bus

N Weight (without mezzanines and accessories): 237g

Interfaces

N PCI Spec. 2.2 compliant 32-bit data bus, 33MHz, 3.3V
N Two 10/100Mbits/s Ethernet channels

Environmental Specifications

Busless SBCs N 82559ER controller

Mezzanine Extensions

N Temperature range (operation):
N RJ45 at front panel with two LEDs
N Two PMCs
N 0..+60°C or -40..+85°C
N One RS232 UART (COM1)
N Compliant with PMC standard IEEE 1386.1
N Airflow: min. 10m³/h
N 16-byte transmit/receive buffer

Miscellaneous

N Temperature range (storage): -40..+85°C
N RJ45 at front panel
N Serial real-time clock with integrated 56-byte NVRAM
N Relative humidity (operation): max. 95% nc
N One UART (COM2)
N Relative humidity (storage): max. 95% nc
N 16-byte transmit/receive buffer
N Serial hardware watchdog in supervisory circuit
N Altitude: -300m to + 3,000m
N Physical interface using SA-Adapter
™ via 10-pin ribbon cable on I/O connector
N Shock: 15g/11ms
N Power supply via on-board 4-pin power connector
N Bump: 10g/16ms
N RS232..RS485, isolated or not: for free use in system (e. g. cable to front)
N Vibration (sinusoidal): 2g/10..150Hz
N Temperature sensor
N Conformal coating on request
N Two MPC8245 UARTs
N Hex switch for user settings
N Accessible via I/O connector
N User LEDs (external)

SC13B – with M-Modules

™

3 M-Module slots

SC13A – with PC-MIPs

®

3 PC-MIP slots (Type I/II)

AD67 – I/O Extension for SC13

3 SA-Adapters (serial I/O)

2 PS/2

46

1 USB
