MEN VMEbus

A12C – 6U VMEbus MPC8245 SBC / PMC

PowerPC

MPC8245/300MHz

1-slot VMEbus master and slave

512MB DRAM, CompactFlash

® N

Graphics via PMC

Dual 10/100Mbit Fast Ethernet

4 COMs, USB, IDE, keyboard/mouse

2 PMC slots

MENMON

™

BIOS for PowerPC

cards CPU

N Two UARTs (COM3/COM4)
N PowerPC
® MPC8245
N Accessible via I/O connector
VMEbus N 300MHz
N Physical interface using SA-Adapter
™ via 10-pin ribbon cable on I/O connector
N Double precision FPU

Local PCI Bus Memory

N RS232..RS485, isolated or not: for free use in system (e. g. cable to front)
N 32-bit/33-MHz, 3.3V V(I/O)
N L1 Cache integrated in MPC8245
N Compliant with PCI Specification 2.2
N Up to 512MB SDRAM system memory
N Handshake lines: none

VMEbus

N One 144-pin SO-DIMM slot for SDRAM modules
N PS/2 keyboard/mouse
N Slot-1 function with auto-detection
N Accessible via I/O connector
N Master
N 100MHz memory bus frequency
N Requires external PHY
N D08(EO):D16:A24:A16
N 2MB Flash

Mezzanine Slots

N Transfer rate max. 7MB/s
N Serial EEPROM 2KB for factory settings
N Two PMC slots
N Slave
N CompactFlash
® card interface
N Compliant with PMC standard IEEE 1386.1
N D08(EO):D16:A24:BLT
N Via on-board IDE

Miscellaneous

N Transfer rate max. 15MB/s
N Type I
N Serial real-time clock with integrated 56-byte NVRAM
N Up to 1MB dual-ported fast SRAM
N True IDE
N Interrupter D08(O):I(7-1):ROAK

Mass Storage

N Serial hardware watchdog in supervis. circuit
N Interrupt handler D08(O):IH(7-1)
N Parallel IDE (PATA)
N Temperature sensor
N Single level 3 fair requester
N One port for local CompactFlash
® N User LEDs (external)
N Single level 3 arbiter
N One port for local hard-disk drive
N Hex switch for user settings
N Bus timer
N Drive can be connected via ribbon cable or mounted directly on the CPU board using MEN adapter kit
N Only one VMEbus slot needed even with hard disk

I/O

N USB
N One USB 1.1 port
N Available via I/O connector
N External PHY
N Data rates up to 12Mbits/s
N Ethernet
N Two 10/100Base-T Ethernet channels
N RJ45 connector at front panel with two LEDs
N One RS232 UART (COM1)
N RJ45 connector at front panel
N 16-byte transmit/receive buffer
N Handshake lines: CTS, RTS; DCD, DSR, DTR
N One UART (COM2)
N Accessible via I/O connector
N Physical interface using SA-Adapter
™ via 10-pin ribbon cable on I/O connector
N RS232..RS485, isolated or not: for free use in system (e. g. cable to front)
N 16-byte transmit/receive buffer
N Handshake lines: CTS, RTS; DCD, DSR, DTR; RI
