MEN CompactPCI

D203 – 6U CompactPCI

®

/PXI

™

M-Module

™

Carrier Board D202 – 6U CompactPCI

N 1 CompactPCI
® bus slot
N 4 M-Module
™ slots
N Full PXI
™ trigger support
N Flexible PXI
™ trigger routing
CompactPCI ®

PXI

™

PC-MIP

®

Carrier Board

N 1 CompactPCI
® bus slot
N 1 PXI
™ slot
N 6 PC-MIP
® slots

CT1 – RIO Module for D202

N 6U/80mm format
N For use of standard connectors

25
