D3B – 6U CompactPCI

MPC8245 SBC / M-Module

™

N PowerPC
® MPC8245 with 603e core
N 1-slot CompactPCI
® system slot
N 512MB DRAM, CompactFlash
® N Dual Fast Ethernet
N 4 COMs, USB, IDE, keyboard/mouse
N 3 M-Module
™ slots
N MENMON
™ BIOS for PowerPC
® cards
CompactPCI

D3A – 6U CompactPCI

MPC8245 SBC PC-MIP AD67 – I/O Extension for D3

® N PowerPC
® MPC8245 with 603e core Connectors manufacturer for:
N 1-slot CompactPCI
® system slot
N 3 SA-Adapters (serial I/O)
N 512MB DRAM, CompactFlash
® N 2 PS/2
N Graphics via PC-MIP
® N 1 USB
N Dual Fast Ethernet
N 1 2.5" hard disk
N 4 COMs, USB, IDE, keyboard/mouse
N 3 PC-MIP
® slots (Type I/II)
N MENMON
™ BIOS for PowerPC
® cards

23
