MEN CompactPCI
F301 – 3U CompactPCI
®
N 8 HP 32-bit/33-MHz CompactPCI
® N Up to 8 Fast Ethernet ports (front)
N 1 Fast Ethernet controller (rear J1)
N Option: 1 Fast Ethernet port (rear J2)
N -40 to +85°C with qualified components Electrical Specifications
N Supply voltage/power consumption:
N +5V (-3%/+5%), 1200mA max.
N +3.3V (-3%/+5%), 400mA max.
N MTBF: 442,000h @ 40°C (derived from MIL-HDBK-217F)
Mechanical Specifications
N Dimensions: conforming to CompactPCI
® specification for 3U boards
N Weight: 200g
Environmental Specifications
N Temperature range (operation):
N -40..+85°C
N Airflow: min. 10m³/h
N Temperature range (storage): -40..+85°C
CompactPCI Ethernet CompactPCI
® Bus
N Relative humidity (operation): max. 95% nc
N 9-port Ethernet switch device KS8999
N Compliance with cPCI
® Specification 2.0 R3.0
N Relative humidity (storage): max. 95% nc
N Eight 10/100Base-T transceivers
N Only one slot required on the 3U cPCI
® bus
N Altitude: -300m to + 3,000m
N Nine MAC units with integr. Layer 2 switch
N Peripheral slot
N Shock: 15g/11ms
N 82551ER Fast Ethernet Controller
N Compliance with PCI Specification 2.1
N Bump: 10g/16ms
Peripheral Connections
N 32-bit/33-MHz PCI-to-PCI
industrial bridge N Vibration (sinusoidal): 2g/10..150Hz
N Via front panel on 8 RJ45 / 6 D-Sub plug conn.
N V(I/O): +3.3V or +5V (Universal Board)
N Conformal coating on request
®
PCI-104 Carrier Board
N 1 PCI-104 slot
N For stacking of up to 4 PCI-104 modules
N 8 HP CompactPCI
® with one PCI-104 module
N PCI-to-PCI bridge PCI-104 Electrical Specifications
N One slot for PCI-104
N Supply voltage/power consumption:
N Up to four stacked PCI-104 modules
N +5V (-3%/+5%), 40mA max. (without PCI-104 module)
N 8HP solution with 1 PCI-104 module mounted
N Second front panel as needed (
filler panel or with connector cut-outs)
N +3.3V (-3%/+5%), 60mA max. (without PCI-104 module)
N Shock: 15g/11ms
N Bump: 10g/16ms
Peripheral Connections
N MTBF: tbd. @ 40°C (derived from MIL-HDBK-217F)
N Vibration (sinusoidal): 2g/10..150Hz
N Via front panel
N Conformal coating on request
Local PCI Bus Mechanical Specifications Safety
N 32-bit/33-MHz, 3.3V or 5V (on req.) V(I/O)
N Dimensions: conforming to CompactPCI
® specification for 3U boards
N PCB manufactured with a flammability rating of 94V-0 by UL recognized manufacturers
N Compliant with PCI Specification 2.2
CompactPCI
® Bus
N Front panel: aluminum with 1 handle
EMC
N Compliance with CompactPCI
® Core Specification PICMG 2.0 R3.0
N Weight: 170g
N Tested according to EN 55022 (radio distur bance), IEC1000-4-2 (ESD) and IEC1000-4-4 (burst) with regard to CE conformity
Environmental Specifications
N Peripheral slot
N Temperature range (operation):
N Only one slot required on 3U cPCI
® bus
N -40..+85°C
N PCI2050 PCI-to-PCI bridge
N Airflow: min. 10m³/h
N Max. clock frequency 33MHz
N Temperature range (storage): -40..+85°C
N 32-bit/33-MHz PCI-to-PCI bridge
N Relative humidity (oper.): max. 95% nc
N V(I/O): +3.3V or +5V (Universal Board)
N Relative humidity (storage): max. 95% nc
N Altitude: -300m to + 3,000m
