29 Product Portfolio Wireless IC Products Evaluation Boards and Development Kits Melexis Order number* Description Contents EVB71101-XXX-YY-Z Evaluation Board for TH71101 Receiver PC Board w/ connector input and receiver circuit featuring TH71101 receiver chip EVB71102-XXX-YY-Z Evaluation Board for TH71102 Receiver PC Board w/ connector input and receiver circuit featuring TH71102 receiver chip EVB71111-XXX-YY-Z Evaluation Board for TH71111 Receiver PC Board w/ connector input and receiver circuit featuring TH71111 receiver chip EVB71112-XXX-YY-Z Evaluation Board for TH71112 Receiver PC Board w/ connector input and receiver circuit featuring TH71112 receiver chip EVB71121-XXX-Z Evaluation Board for MLX71121 Receiver PC Board w/ connector input and receiver circuit featuring MLX71121 receiver chip EVB71122-XXX-Z Evaluation Board for MLX71122 Receiver PC Board w/ connector input and receiver circuit featuring MLX71122 receiver chip EVB7122-XXX-YY-Z Evaluation Board for TH7122 Receiver PC Board w/ RF connector I/O and transceiver circuit featuring TH7122 and TH71121 transceiver chips EVB72005-XXX-YY-Z Evaluation Board for TH72005 Transmitter PC Board w/ printed loop antenna and transmitter circuit featuring TH72005 transmitter chip and TH72001/02 functionality EVB72006-XXX-YY-Z Evaluation Board for TH72006 Transmitter PC Board w/ connector output and transmitter circuit featuring TH72006 transmitter chip EVB72015-XXX-YY-Z Evaluation Board for TH72015 Transmitter PC Board w/ printed loop antenna and transmitter circuit featuring TH72015 transmitter chip and TH72011/12 functionality EVB72016-XXX-YY-Z Evaluation Board for TH72016 Transmitter PC Board w/ connector output and transmitter circuit featuring TH72016 transmitter chip EVB72035-XXX-YY-Z Evaluation Board for TH72035 Transmitter PC Board w/ printed loop antenna and transmitter circuit featuring TH72035 transmitter chip and TH72031/32 functionality EVB72036-XXX-YY-Z Evaluation Board for TH72036 Transmitter PC Board w/ connector output and transmitter circuit featuring TH72036 transmitter chip EVB90109 Evaluation Board for MLX90109 Evaluation board of transceiver + antenna, featuring the MLX90109 DVK90109 Development Kit for MLX90109 Includes EVB90109, 125 KHz tags and board with microcontroller EVB90121 Evaluation Board for MLX90121 Evaluation board of transceiver + antenna, featuring the MLX90121 DVK90121 Development Kit for MLX90121 Includes EVB90121, 13.56 MHz tags and board with microcontroller DEMO90121LR RFID Long Range Reader Demonstrator Demonstrator of RFID high power reader (1W) for logistic application based on MLX90121 EVB90129 Evaluation Board for MLX90129 Sensor Tag & data logger evaluation board featuring the MLX90129 DVK90129 Development Kit for MLX90129 Includes EVB90129, ProximaRF® reader and user interface software * U se key below to specify options: XXX = 315 or 433 or 868 or 915 (operating frequency in MHz) YYY = FSK or ASK (modulation) Z = A or C (antenna or connector board)
