Pressure Sensitive Mats Pressure sensitive mats are protective devices used for protecting areas. They comprise sensor, control device and output signal switching device(s).

Polymer Electric

Proven Safety

Safety Mats - 29520 Safety MatsProduct Range

1.1.1

Control device sensorcontrol device Sensor The control device is that part of the pressure sensitive mat which converts the output signal transmitted by the sensor and controls the state of the output signal switching device. The output signal switching device is that part of the control device which is connected to the machine control system and transmits safety output signals. The control unit is made up ofcontrol device and output signal switching device(s). Actuating force The sensor is that part of the pressure sensitive mat which produces a control command when the actuating force is applied. The sensor of the pressure sensitive mat is a flat surface area. The effective sensing areas can be fitted with additional covering (e.g. with a non-slip topping).
output signal switching device machinecontrol system Pressure Sensitive Mat The following points should be considered when choosing the sensors: -temperature range -response time -protection class (standard: IP65) -environmental considerations (metal swarf, oil, fluids, ...) - NOT suitable for children sensorsensor outputcontrol unit Single sensors: Combination of sensors: -suitable for children weighing more than 20 kg PLEASE NOTE: The certification of design becomes invalid if our products are used in combination with control units or sensors which do not comply with the tested types.
Subject to technical modifications. 210498 Mayser Polymer Electric P.O.Box 3048 D-89020 Ulm Tel. +49-731/2061-0 Fax +49-731/2061-222
