Cable connection

Safety Mats - 29520 Safety MatsProduct Range

1.4.1 Cable exit

The cable exits are in the middle of the mat sides.In the case of the SM/BK the cable entries are 50 mm apart. The plugs and sockets are moulded onto the cable and are watertight. ∅ 5 mm; 4 x 0.25 mm ∅ 5 mm; 2 x 0.5 mm
2 Cu) -single or end mat SM/W-integrated resistor -2-wire cable(
2 Cu) ∅ 5 mm; 2 x 0.5 mm with plug
2 Cu) -easy servicing -simple installation -reliable connection -watertight plug-in connection -through mat SM/BK-no resistor -2-wire cable( without plug -all-purpose -length of cable can be varied -through mat SM/BK-no resistor -4-wire cable( The multifunctional cable exit also allows the cable to be laid vertically or horizontally.
Subject to technical modifications. 210498 Mayser Polymer Electric P.O. Box 3048 D-89020 Ulm Tel. +49-731/2061-0 Fax +49-731/2061-222
