product guide features • 44 - 223 ft. (13.3 - 68 m) 7 section full power Mega Form boom with Twin Lock pinning • 39 - 69 ft. (12 - 21 m) hydraulic offset bi-fold swingaway • 2 x 26 ft. (8 m) intermediate lattice inserts • 169,700 lb. (77 t) counterweight with hydraulic removal system • MEGATRAK independent hydro-pneumatic suspension GMK5275 All Terrain Crane contents Features 2 Specifications 3 Dimensions 5 Travel Proposal 6 Specifications 7 Dimensions 9 Travel Proposal 10 Counterweight Dimensions 11 Working Range Main Boom 12 Load Charts 13 Working Range Hydraulic Offset Swingaway 16 Hydraulic Offset Swingaway Charts 18 Working Range Heavy Duty Jib 21 Load Chart Heavy Duty Jib 23 www.manitowoc.com
