OTHER PRODUCTS
For over 50 years, Magtrol Inc and Magtrol SA have been providing customers with high quality products to test, measure and control torque-speed-power, load-
force-weight, tension and displacement. Magtrol Inc, headquartered in the USA, is a leading manufacturer of motor test equipment and hysteresis brakes and industrial clutches. Magtrol SA, located in Switzerland, also offers motor test equipment as well as transducers to measure, monitor and control load, force, weight and displacement. Magtrol offers customers a wide array of test and measurement solutions, combined with excellent worldwide sales and service.
Highly reliable systems to measure and monitor load, force and weight, commonly used to provide safety, control and overload protection. Typical applications requiring Load-Force-Weight Systems include cranes, harbor installations, oil drilling (on and off shore),
industrial hoists, winches and other heavy
lifting equipment. The systems are extremely accurate, can be used for static or dynamic measurement, and are able to withstand the most extreme environmental conditions. Features include: Nominal value up to 2500 kN; Accuracy class < 0.5%; Protection up to IP67; Transducer made of high resistance stainless steel; Overload admissible 150%; Overload at rupture up to 500%; Test and certificate for component to CE standards and material certificate on request; Analog or digital
signal conditioner with inputs up to 2 channels, 0–10 V, 4–20 mA outputs or bus interface, and digital display.
Used to provide precise tension and torque control in many types of applications such as textile, coil winding,
EDM, wire and
fiber optic cable manufacturer, printing and packaging. Features include: Torque up to 3500 oz·in; Speed up to 20,000 rpm; Power up to 2400 W; Metric or English dimensions; Standard or customized brakes and clutches available.
Power supplies, matched brakes, torque curves and other options are also available.
Provides contactless measurement of absolute piston position in hydraulic and
pneumatic cylinders, and other applications. Features include: Accuracy of 0.3%; Range from 50 mm to 1 m; High shock and vibration resistance; Ability to withstand pressure up to 450 bar; Operating temperature of -40 °C to +80 °C with active temperature compensation. High temperature version up to 200 °C available.
Rotary Transmitters
7 ; Noise 25 µV; Very low inertia; No
slip rings.
M AGTROL INC
Used for signal transmission of transducers on a rotating part (e.g. engine shaft) to a stationary system (measuring instrument or PC). Common applications include
thermocouples and
strain gauges, as well as piezo electric transducers to measure oscillation, acceleration, force and pressure. The transmitter can also provide the supply signal to each transducer. Features include: 1, 4, 8 or 12 channels; Speed up to 40,000 rpm; Resistance < 0.2 m
70 Gardenville ParkwayBuffalo, New York 14224 USAPhone: +1 716 668 5555Fax: +1 716 668 8705E-mail: magtrol@magtrol.com
MAGTROL SA
Due to the continual development of our products, we reserve the rightto modify specifications without forewarning.
Centre technologique Montena1728 Rossens/Fribourg, SwitzerlandPhone: +41 (0)26 407 3000Fax: +41 (0)26 407 3001E-mail: magtrol@magtrol.ch
For more information, contact your local sales agent: For worldwide network of sales agents, visit our web site:Subsidiaries in:Germany • France • U.K. • China
