STANDARD LOAD PINS


Model	Nominal Load		Nominal Diameter (mm)
Model	(kN)	(tf)	Nominal Diameter (mm)
LB 210	2.5	0.28	25
LB-LE 211 / LB 231	5	0.56	25
LB-LE 212 / LB 232	10	1.12	25
LB-LE 213 / LB 233	20	2.25	25
LB-LE 214 / LB 234	50	5.62	35
LB 235	70	7.87	45
LB-LE 216 / LB 236	100	11.24	50
LB-LE 217 / LB 237	200	22.48	65
LB-LE 218 / LB 238	500	56.20	85
LB-LE 220 / LB 240	1000	112.40	100
LB-LE 221 / LB 241	1250	140.50	120

Load pins are industrial measuring devices used to measure loads and detect overloads. The pins are mounted into machines in place of normal, non-instrumented pins or shafts and fitted with strain gauges allowing them to produce a signal proportional to the measured load.

Features

• From 2.5 to 1250 kN (0.28 to 140.5 tf)

• Admissible overload: 150% of the nominal load

• Overload at rupture: 350% to 700% of nominal load

(according to the model)

• Made of high resistance stainless steel

• Not affected by external mechanical and chemical conditions (strain gauges inside the pin) and therefore ideal for use in harsh environments

• Rugged and tight construction; maintenance-free

• For new or refitted installations

• ISO 9001 Certified

LB 210 Series

Available in 10 standard ranges from 2.5 to 1250 kN (0.28 to 140.5 tf) Temperature-compensated transducers with strain gauges in single full-bridge configuration; Bridge impedance: 350 Q

Accuracy: 0.5% to 0.8% of FSD (according to the type of pin) High reliability for your safety requirements

Rugged design for application in harsh industrial environments (IP 66) Standard version available with variants (cable length, lubrication, etc.) Output: 0.5 to 1.8 mV/V (depending on size)

LB 230 Series

Available in 10 standard ranges from 5 to 1250 kN (0.56 to 140.5 tf) Temperature-compensated transducers with strain gauges in double full-bridge configuration; Bridge impedance: 700 Q Accuracy: < 0.4% of FSD

Certified according to OIML R60 D0.1 from 50 to 200 kN for class IIII scales

Hermetically sealed for harsh environmental conditions (IP 67)

Axial forces compensated for better accuracy; Insensitive to lateral forces

Dimensions compatible with the standard LB 210 Series

Output: 0.5 to 1.8 mV/V (depending on size)

LE 210 Series

Available in 9 standard ranges from 5 to 1250 kN (0.56 to 140.5 tf) Temperature-compensated transducers with strain gauges in single full-bridge configuration; Bridge impedance: 5000 Q

Accuracy: 0.5% to 0.8% (according to the type of pin) Integrated 2-wire signal amplifier for transmission over great distances EMC execution for reliable trouble-free operation

Rugged design corresponding to the quality characteristics and dimensions of the LB 210 Series Output: 4 to 20 mA
