Group: AMETEK
Catalog excerpts
Magnetrol: A Heritage Of Leading-Edge Products Created Through Engineering Excellence. LEADERSHIP Since we invented and marketed our first level control in 1932, the Magnetrol name has become synonymous worldwide with quality and innovation. Today Magnetrol products serve industries in over 100 countries. Our market leadership is sustained by a strong ongoing commitment to advance the state-of-the-art in level and flow technologies. SOLUTIONS Because process environments are so diverse, Magnetrol has created numerous technology groups to address the broad range of control challenges. Each...
Open the catalog to page 2PACTware™ Process Automation PC Software Description: PACTware (Process Automation Configuration Tool) is a device-independent software program that communicates with all approved DTMs. Measurement Principle: N/A (Software) Applications: Use with device specific software drivers - DTMs (Device Type Managers) Features: • Device diagnosis and Troubleshooting • Online/offline parameterization • Many languages supported, including English, German and French Options: RS232-HART® or USB HART interface Eclipse® Model 705 GWR Transmitter Description: A 24 VDC, loop-powered transmitter. Not affected...
Open the catalog to page 3Echotel® Model 910 Level Switch Description: Integral mount, low cost ultrasonic level switch with worldwide safety approvals. Measurement Principle: Continuous wave ultrasonic Applications: Clean liquids, wastewater, petrochemical, foods and pharmaceuticals, solvents Features: • Tip sensitive gap style • Integral mount unit with dual conduit hubs • Field selectable high or low level failsafe • 10A DPDT gold flash or 5A DPDT hermetically sealed relay • Vertical or horizontal mount • No calibration required • Two-year warranty Options: Housings, process connections, input power, relay type,...
Open the catalog to page 4Top Mount Float Type Level Switch Description: A simple and reliable float switch designed for top mounting on virtually any process or storage vessel. Measurement Principle: Buoyancy Applications: Virtually any tank or vessel; condensate receivers, cooling towers, interface detection Features: • Single or tandem float configurations • Rugged reliability • Wide selection of switches • Actuating depths of up to 48" (1219 mm) • Simple operation • Maintenance free • Variety of process connections Options: Single or tandem units, tank connection type and float size, NACE construction, electric...
Open the catalog to page 5THE RMA L D I S P E R S ION Thermatel® Models TD1/TD2 Flow/Level Switch Description: Reliable flow/level/interface switch detects changes in heat transfer due to changes in media or changes in flow velocity. Measurement Principle: Changing temperature difference activates relay Applications: Flow switch for both gas and liquids. Level/ interface detection between different media. Features: • Continuous diagnostics with fault detection • Temperature compensation • mA output signal on TD2 permits flow monitoring and diagnostics • Temperatures to +850° F (+450° C), pressure to 6000 psig (410...
Open the catalog to page 6Real World Solutions Magnetrol International designs, manufactures, markets and services level and flow instrumentation for the process industries worldwide. Oil & Gas Production Petroleum Refining Chemical Biotechnology Water & Wastewater Food & Beverage Pharmaceutical Power Generation Discover more by visiting magnetrol.com, by e-mailing us at info@magnetrol.com or by calling 1-800-624-8765
Open the catalog to page 7CORPORATE HEADQUARTERS 5300 Belmont Road • Downers Grove, Illinois 60515-4499 USA Phone: 630-969-4000 • Fax: 630-969-9489 magnetrol.com • info@magnetrol.com EUROPEAN HEADQUARTERS Heikensstraat 6 • 9240 Zele, Belgium Phone: 052 45.11.11 • Fax: 052 45.09.93 BRAZIL: Av. Dr. Mauro Lindemberg Monteiro • 185-Jd. Santa Fé, Osasco • São Paulo CEP 06278-010 CANADA: 145 Jardin Drive, Units 1 & 2 • Concord, Ontario L4K 1X7 CHINA: Room #8008 • Overseas Chinese Mansion • 129 Yan An Road (W) • Shanghai 200040 DEUTSCHLAND: Alte Ziegelei 2–4 • D-51491 Overath DUBAI: DAFZA Office 5AE 722, P.O. Box 293671 •...
