Standard CAT5/5e/6 TypePart No. Ethernet cables LÜTZE ELECTRONIC ETHERNET CAT5 UTP(4x2xAWG24/1) 100 MHZ104350 (wiring cable for office LÜTZE ELECTRONIC ETHERNET CAT5 STP(4x2xAWG24/1) 100 MHZ104351 environment) LÜTZE ELECTRONIC ETHERNET CAT5 STP-C(4x2xAWG24/1) 100 MHZ104352 LÜTZE ELECTRONIC ETHERNET CAT5e UTP(4x2xAWG24/1) 200 MHZ104353 LÜTZE ELECTRONIC ETHERNET CAT5e STP(4x2xAWG24/1) 200 MHZ104354 LÜTZE ELECTRONIC ETHERNET CAT5e STP-C(4x2xAWG24/1) 200 MHZ104355 LÜTZE ELECTRONIC ETHERNET CAT6 UTP(4x2xAWG23/1) 300 MHZ104356 LÜTZE ELECTRONIC ETHERNET CAT6 STP(4x2xAWG23/1) 300 MHZ104357 LÜTZE ELECTRONIC ETHERNET CAT6 STP-C(4x2xAWG23/1) 450 MHZ104358Fibre optics and assemblies upon request. ConnectorsTypePart No. RJ45 connector data for Superflex Bus Ethernet cables 4 pole black IP20686011 RJ45 connector push pull for Superflex Bus Ethernet cables 4 pole black IP67686012 RJ45 connector 3A data for Superflex Bus Ethernet cables 4 pole black IP67686013 RJ45 connector 3A data metal for Superflex Bus Ethernet cables 4 pole IP67686014 M12 connector 0°D coded for IP67 Ethernet connections686072 M12 connector 90°D coded for IP67 Ethernet connections686073 Standard patch cables,Type Length / m DataPart No. shielded, grey RJ45/RJ45 Straight grey* 0,5 CAT5/SFTP192000 RJ45/RJ45 Straight grey*1CAT5/SFTP192001 RJ45/RJ45 Straight grey*2CAT5/SFTP192002 RJ45/RJ45 Straight grey*3CAT5/SFTP192003 RJ45/RJ45 Straight grey*5CAT5/SFTP192004 RJ45/RJ45 Straight grey*10CAT5/SFTP192005 RJ45/RJ45 Crossover red*0,5CAT5/SFTP192050 RJ45/RJ45 Crossover red* 1CAT5/SFTP192051 RJ45/RJ45 Crossover red* 2CAT5/SFTP192052 RJ45/RJ45 Crossover red* 3CAT5/SFTP192053 RJ45/RJ45 Crossover red*5CAT5/SFTP192054 RJ45/RJ45 Crossover red*10CAT5/SFTP192055*Cable bushing.M12/M12 versions on request. Accessories Type Part No. DIN rail patch box (2xRJ45 for 2 CAT5 cables)680500 DIN rail patch panel (4xRJ45) 680501
Cable assemblies Our abilities include:
• Design of customer specific Ethernet connection cables
• No minimum order quantity DIN rail patch box M12 IP67Connectors, field wireableRJ45 IP67RJ45 IP20RJ45 IP67RJ45 IP67
