> WHY DIGITAL?

> VGA CAMERA MODELS

USB 2.0 and Ethernet represent a more efficient means to interface your vision system to a host computer. With all new computers providing na­tive support for both USB 2 .0 and 10/100baseT Ethernet, there is no need for 3rd party framegrabbers and bulky cables. One USB 2.0 cable provides power, video, and camera control.

Additional benefits:

• Higher resolution than analog NTSC/PAL

• Progressive scan for high-speed capture

• Lower system cost

• Time-to-market with ease of integration

Lu070/Lu075

•640x480 resolution

• 60 fps at full resolution •1/3" Sony CCD sensor

• Color or monochrome

• Board level or enclosed

The Lu070/Lu075's high-speed and excellent sensitivity are ideal for high quality imaging applications.

Lu080/Lu085

• 640x480 resolution •1/2" CMOS sensor

• 65 fps at full resolution

• Color or monochrome

• Board level or enclosed

> WHY MEGAPIXEL?

The superior image quality of megapixel resolution represents the new era of industrial imaging, providing:

• More precise measurement • Detection of smaller defects

• Better location accuracy • Faster scanning of large objects

Global shutter for freeze frame of moving objects, and high frame rates make the Lu080/Lu085 ideal for machine vision applications.

> MEGAPIXEL CAMERA MODELS

Lu100/Lu105

• 1280x1024 resolution

•1/2" CMOS 1.3 megapixel sensor •15 fps at full resolution •Color or monochrome

• Board level or enclosed

Lu160/Lu165

• 1392x1040 resolution

• 2/3" Sony EXview HAD CCD 1.4 megapixel sensor

• 15 fps at full resolution, faster with binning •Color or monochrome

• Board level or enclosed

The Lu100/Lu105's SXGA provide four times the resolution of VGA. Good sensitivity and half-global shutter are appropriate for still imaging.

The Lu160/Lu165 offer the highest sensitivity of all our industrial cameras. Coupled with increased sensitivity and excellent color reproduction, these camera models will satisfy the most demanding imaging applications. Other features include a global shutter and low dark current. Also offered in a scientific grade with optional cooling.

Lu120/Lu125

• 1280x1024 resolution

•2/3" CMOS 1.3 megapixel sensor •15 fps at full resolution •Color or monochrome

• Board level or enclosed

Lu170/Lu175

• 1280x1024 resolution

•1/2" CMOS 1.3 megapixel sensor •15 fps at full resolution •Color or monochrome

• Board level or enclosed

The Lu120/Lu125 use a global shutter for high-speed motion capture and also provide a rolling shutter. High dynamic range of +100dB with multi-slope integration mode. Additional lighting or LED strobes recommended for short exposures due to sensitivity.

The Lu170/Lu175 provide faster frame rates with smaller region of interest. Good sensitivity and very low noise make this sensor similar to CCD performance. Also offered in a scientific grade.

Lu130/Lu135

•1392x1040 resolution

• 1/2" Sony CCD 1.4 megapixel sensor •15 fps at full resolution

•Color or monochrome

• Board level or enclosed

Example Camera Applications

Global shutter with excellent sensitivity make the Lu130/Lu135 ideal for high-end industrial applications. Excellent replacements for any customer using Basler, Sony XCD series or similar cameras. Also offered in a scientific grade.
