Features • Designed for dairy, brewing, food and process applications • Two 4-20mA outputs and RS485 interface • 3 line 12 character integral display • Fully configurable operation via Windows™ software • Measurement of conductivity, % solution concentration, salinity & temperature • IP66 stainless steel enclosure • Peek detachable Electrodeless conductivity sensor • Steam sterilisable to 135°c, thermal shock resistant • Fast temperature response t90 < 10 secs • Can be configured and calibrated before shipment • Low cost connection cable • Low voltage operation • Simple installation • A choice of sensor process connections

The IET40 series of transmitters sets new standards for the measurement of conductivity in process applications. The one unit measures conductivity over the range of 500 us/cm to 1,000ms/cm. Temperature is also measured to an accuracy of better than 0.2°C. The two measurements are combined within the transmitter and using Windows™ software the 4-20mA outputs can be configured to measure in conductivity, % solution concentration, temperature, PPM or salinity. Alternatively a standard RS485 interface provides controlled access to all of the configuration parameters and measurements on-line. Operator...

Output Ranges (Assigned to any of the outputs) Conductivity 0 - 1000mS/cm can be expanded to a minimum conductivity span of 0.2mS/cm and offset anywhere in the measurement range. Can be configured with or without temperature compensation. Specifications Sensor details ECS/56T Insertion 1.5 BSP thread (Not shown) ECS/57T Insertion 1.5 BSP thread (Not shown) ECS/58T Short Hygienic - can be fitted with Varivent Flange (Not shown) ECS/59T Hygienic can be fitted with DIN, triclamp, RJT or IDF flange Wetted materials PEEK, 316 Stainless steel, EPDM Seal Sensor specification Maximum Temperature 100°C Continuous,...

LTH Electronics Ltd, Chaul End Lane, Luton, Bedfordshire. LU4 8EZ England Telephone: +44 (0)1582 593693 Fax: +44 (0)1582 598036 email: [email protected] web: www.lth.co.uk Electronics Specifications (cont.) Total dissolved solids Calculated from the conductivity measurement using an adjustable factor of 0.1 to 10 Temperature -20 to +150°C Temperature compensation Adjustable 0 - 20%/°C, base 20°C or 25°C. Display Integral 3 line 36 character backlit LCD display to show measured values, output currents and error messages. Ambient temp. -20 to +50°C Enclosure IP66 Stainless Steel Power supply 12 -...
