Lovejoy
Model 13207 Spring-Loaded Driver Pulley
Hexadrive Series
One-Side Moveable Adjustable Center Distance
UPC Number
Bore in
PD
Torque Capacity in-lb
HP Rating i
Min in
Max in
1750 RPM
1150 RPM
42433
1-1/8
4.43
10.35
270
7-1/2
5
37344
1-3/8
37345
1-5/8
Model 13210 Spring-Loaded Driver Pulley
UPC Number
Bore in
PD
Torque Capacity in-lb
HP Rating i
Min in
Max in
1750 RPM
1150 RPM
21892
1-3/8
4.43
10.35
360
10
7-1/2
21893
1-5/8
21894
1-7/8
5 through 30 HP
2.25 ONLY -H AT MAX P.D.
3230 HV Belts
Ratio 2.3 to 1
CD
(CENTER DISTANCE)
Model 13220 Spring-Loaded Driver Pulley
Bore
PD
Torque
HP Rating I
UPC
Min
Max
Capacity
1750
1150
Number
in
in
in
in-lb
RPM
RPM
21915
1-3/8
21916
1-5/8
4.43
10.35
720
15 to 20
10 to 15
27974
1-7/8
Model 13230 Spring-Loaded Driver Pulley
Bore
PD
Torque
HP Rating I
UPC
Min
Max
Capacity
1750
1150
Number
in
in
in
in-lb
RPM
RPM
37348
1-3/8
37349
1-5/8
4.43
10.35
1,080
25 to 30
20 to 25
42439
1-7/8
42440
2-1/8
v
3230hv belt
APPROX. MOTOTR TRAVEL CD.-
13207/13210 /13220 /13230 Driven Sheave Selection Table
Flat Driven Sheave
Driven Speed Range
Driven Torque i
Model
PD
1750 RPM Motor
1550 RPM Motor
13207
13210
13220
13230
UPC
Min
Max
Min
Max
Number
in
RPM
RPM
RPM
RPM
in-lb
in-lb
in-lb
in-lb
19639
4.25F12SF*
13.0
600
1,390
395
915
243
324
*
*
19641
4.25F14SF
15.0
520
1,205
340
790
283
378
756
1,134
19643
4.25F16SF
17.0
460
1,065
300
700
324
432
864
1,296
19645
4.25F18SF
19.0
410
950
270
625
364
486
972
1,458
19647
4.25F20SF
21.0
370
860
245
565
405
540
1,080
1,620
19651
4.25F24SF
25.0
310
720
205
475
486
648
1,296
1,944
NEMA Motor Frame
Recommended Motor Bases
213T, 215T
305-8, SMB 254
254T
310-30, SMB 254
256T, 284T
310-30
286T, 324T
Note: ■ * indicates: That 4.25F12SF is NOT recommended for use with 15 to 30 HP drive. This combination could cause belt slippage.
13207/13210 /13220 /13230 Belt Selection Table
o
CO
>
Belt
Minimum Center Distance by Selected Sheave Size I
UPC
Size
4.25F12SF
4.25F14SF
4.25F16SF
4.25F18SF
4.25F20SF
4.25F24SF
Number
in
in
in
in
in
in
23382
3230HV620
12.7
—
—
—
—
—
23384
3230HV670
15.2
13.5
—
—
—
—
23387
3230HV723
17.9
16.2
14.5
—
—
—
23389
3230HV821
22.8
21.1
19.4
17.6
—
—
23390
3230HV856
24.5
22.9
21.2
19.4
17.6
—
23392
3230HV931
28.3
26.6
24.9
23.2
21.4
17.7
23393
3230HV960
29.7
28.1
26.4
24.7
22.9
19.2
Note: ■ When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown in the tables above.
