High Performance Gear

High Speed Spindle Couplings

Overview

Lovejoy / Sier-Bath Flanged Sleeve Type Spindle Couplings
Special Load and No Load Applications For cases where a spindle coupling operates under a load at a given misalignment angle and requires a higher no load misalignment angle, we design special Vari-Crown ® tooth forms. Such forms have compound curvature wherein the Vari-Crown is used for maximum radii of curvature at the load angle. At no load conditions the tooth ends are designed to eliminate edge loading and give proper tangential contact.Available in several designs up to 40-inch diameter. Any variations of the designs shown can be incorporated to fit your application. HP Only a few special types of couplings are illustrated. Additional special types are available on request. Replaceable Gearing Spindle Coupling Special IndexingSpindle Coupling Flanged Sleeve Main DriveSpindle Coupling Leveling and Pinch RollSpindle Coupling Special Roll DriveSpindle Coupling HP-20
212 630-852-0500
