High Performance Gear High Speed Special Couplings

Overview

Lovejoy / Sier-Bath F Type High Speed Standard Couplings

Transmission Test StandHigh Speed Spacer Coupling

Self-contained oil lubrication, normal speed 16,000 RPM, maximum speed 25,000 RPM. The dimensions are similar to a size 2.5, with an overall length of 35 inches and a total weight of 29 lbs.

Light Weight Coupling

Made of extremely light weight, vacuum melted, AMS material with magnetic particle inspection. The overall length is 29.5 inches and the weight is 19.4 lbs.
HP

Test Stand

High Speed Spacer coupling with internal support for instrumentation wires. Maximum speed of 7,000 RPM.

Transmission Test Stand

This High Speed Spacer coupling is grease packed and operates at a maximum speed of 6,000 RPM. Based on a size 3, the overall length is 55 inches.

Single Flange

This High Speed Spacer coupling is grease packed and operates at a maximum speed of 8,000 RPM. The total assembly weight is 19 lbs with an overall length of 19 inches.
