LOGIFLEX ROTATOR
Technical Specifications
The rotator can be set to meet indi-vidual requirements of the customer and has a controller with the following advantages:
ā—¸Easy to set degree of tilt and rotation speed
One or two sets of box holders with or without clamps (optional extras) can be fitted. The Rotator is controlled by remote control with magnet. Easy to set degree of tilt and rotation speed.ā—¸
Precise and controlled acceleration/ deceleration on rotation at start/stop
ā—¸Low maintenance costs - no relays and wearing parts
ā—¸Current consumption reduced by 50%
ā—¸Tilting function is deactivated automatically, when rotating to neutral position
Rotator - 26394 ABC
bb lbTilting function is deactivated when the rotation centre is more than 1180 mm or less than 680 mm above the floor.
h lBox holders with clamps are recom-mended when tilting more than 60°.
560280 1210 564,5282 330585615 A : With two sets of box holders. B : With one set of box holders and one set of box holders with clamps. Recommended when tilting more than 60°. C : Multi-purpose carriage.Product (measured in mm)ELF, ELFSSELF, SELFS CapacityMaximum 1000 kg when the load centre is maximum 80 mm from the rotation centre. The load capacity that can be tilted is reduced, the larger the distance is between load centre of the load and rotation centre.Max. torque 700 NmFork spanb Multi-purpose carriage, which can be adjusted to fit specific customer items.
5 560 or 680Overall width b 1 ELF: 932, SELF: 890 (ELF and SELF: distance between steering wheels: 860)Fork lengthl1250Overall lengthl 1 2000 1955Tilt function355° (with one adjustable stop in every side) (Standard: 45° to every side)Tilt areaForks: 400-900 (h 3) . Multi-purpose carriage: 680-1180 from floor to rotation centreTilt time (0-180°)Minimum 30 sec. (adjustable)Electric motor for tilt function 12 V, 24 A24 V, 12 AMotor specifications 0,2 kw, 3000 r/mGear1:228MotorPermanent magnet motor, IP 44, class F OperationNot continuously (S2= 10 min)Box holder with/without clamps (optional extras)bFor box widths of 800 or 1000 mm by a fork span of 560 mm.For box widths of 1000 or 1200 mm by a fork span of 680 mm. Special arrangements for a maximum box width of 1400 mm are possible.Box holders with clamps can hold boxes of heights between 400 and 1200 mm, when tilted. The rotator can turn a box 180ŗ to empty it fully, when equipped with box holders with clamps.
Please see other dimensions in the leaflets for LF/EFS, LFS/ELFS, SELF and SELFS.
