PANTHER MAXI AC / MINI
Technical Specifications
The trucks are available in two models
●Mini - capacity of 1400 kg - recom- mended for light pallet transport
●Maxi AC - capacity of 1800 kg - recom- mended for heavy pallet transportOptimum space utilisation
Possible to operate with handle upright. Central location of all control buttons.Strong construction ensures a long operating life and low maintenance costs.Easy access to all components makes service of the truck straightforward.
●length behind the forks of 450 mm
●tight turning angle of 210
●narrower than the width of a EUR pallet - it can operate in aisles as narrow as a pallet width
Product (measured in mm)Panther MiniPanther Maxi ACSpecial features for the Panther Maxi AC
Capacity 1400 kg1800 kgLifting heighth 195, 200Fork lengthl810, 915, 970, 1066, 1140, 1220, 1520*Overall heighth●
AC-technology
3 ●Easy service and setting of e.g. driving speed, acceleration and deceleration
1 647817Overall width b5 =520 / b
5 =680b
1 600/680Fork spanb
●
Long operation time per charge
5 520, 680Fork widthe158Length without forksl●
Motor brake - optimum safety
●No brushes in the wheel motor - reduced maintenance
2 450Overall lengthl1 450 + lOverall heighth
14 1296Lowered heighth
13 80, 85Load centrecl / 2Wheel base (l=1140)y1256GangwayA
st 1890** (pallet: 1200 x 800)Turning angle of the wheels210 Turning radius Wa (l=1140)1410 Driving motor - speed control electronically variable24 V DC 0,7 kW24 V AC 1,2 kWDriving speed with/without load4/5 km/h5/6 km/hPump motor24V 0,8 kW24V 1,2 kW Lifting speed with/without load 50/55 mm/s35/50 mm/s Lowering speed with/without load 200/55 mm/s115/40 mm/sGradient performance 10%10%Battery60 Ah (2x12 V)120 Ah (1x24 V) or 160 Ah (1x24 V)Weight in kg with 1140 mm forks (without battery)203205
