LEVEL CONTROL

Technical Specifications

The working height is auto matically maintained - the forks raise when unloading material and lower when loading material.Optimum safety for the user:
â—� A warning lamp flashes when the forks are lifting/lowering
The level control can be placed on either the left or right hand side, and is easy to retrofit. By means of the electric sensor, the forks raise when unloading material and lower when loading material. The truck also functions as ordinary lifting truck . â—� Instant stop makes the lifting/lowering function stop immediately
â—� The bottom stop ensures a clearance Further advantages:
â—� Turnable photocell - can be adjusted according to the location of the goods
â—� Adjustable detection range: From 100 to 1000 mm
â—� Photocell and printed circuit card are protected in a steel box
â—� The top stop protects the motor
Product (measured in mm)HighlifterLogiflex Lifting height activated level controlh 3 800900Lowered height activated level controlh 13 200200 Can be fitted on the electric highlifter and Logiflex range (without telescopic mast) . The height of the photocell can be adjusted. Highlifters: between 490 - 970 mm. Logiflex: between 550 - 920 mm. For protection against crushing injuries (EN 349:1993). The user sets the level control to raise or lower .Control box has adjustable reac-tion time: from 1-10 sec. The level control is shown fitted on a fully powered Logiflex.It can also be fitted on the electric highlifter and Logiflex range. We also offer tailor-made solutions. Please ask for further information or visit our website www.logitrans.com
