Part number example see page 3
HOCHSPANNUNG
HIGH VOLTAGE
BAUFORM Y-SERIE
MODEL Y-SERIES
V
FFA
Straight plug with cable collet
Reference
Dimensions L (mm)
Model
Series
Type
male contact
female contact
ffa
1y
405 /
54
66
ffa
iy
410 /
63
83
ERA
Fixed socket, nut fixing
Reference
Dimensions L (mm)
Model
Series
Type
male contact
female contact
era
1y
405 /
61
51
era
1y
410 /
79
69
PSA
Fixed socket, nut fixing, with cable collet
Reference
Dimensions L (mm)
Model
Series
Type
male contact
female contact
psa
1y
405 /
71
74
psa
1y
410 /
81
93
FFA
Straight plug with cable collet
Reference
Dimensions L (mm)
Model
Series
Type
male contact
female contact
ffa
3Y
415 /
96
105
ffa
3Y
430 /
113
198
6
/ Bei Lemo vorhanden I available at Lemo
