m LEma
Part number example see page 3
FLA Elbow (90°) plug, cable collet
Reference
Dimensions (mm)
Model
Series
a
ai
h
l
m
si
S2
FLA
0S /
13
13
24.5
23.0
13.0
8
6.5
FLA
1S
16
16
28.5
26.5
15.5
10
8.5
FLA
2S /
20
20
37.0
31.0
19.0
13
11.0
FLA
3S /
21
21
44.0
38.5
23.5
15
14.0
FLA
4S
28
28
56.0
49.0
31.0
20
19.0
FLA
5S /
-
37
76.5
65.0
40.0
30
29.0
Note; fig.1 is used for the unipole type. fig.2 is used for the multipole type
ERA Fixed socket, nut fixing
——L maxi—»
S3 .
Reference
Dimensions (mm)
Model
Series
a
b
e
e
l
L'
m
si
S3
—L.
ERA
0S /
10
12.5
M9x0.6
7.0
17.5
18.5
1.2
8.2
11
■ :
T i
m
i
<
ERA
1S ✓
14
16.0
M12x1.0
7.5
20.2
21.5
1.5
10.5
14
ERA
2S ✓
18
19.5
M15x1.0
8.5
24.5
26.0
1.8
13.5
17
f N-VA
ERA
3S ✓
22
25.2
M18x1.0
11.5
29.0
30.0
2.0
16.5
22
E maxi
ERA
4S ✓
28
32.0
M25x1.0
12.0
34.0
36.0
2.5
23.5
30
ERA
5S ✓
40
40.0
M35x1.0
15.5
45.0
78.5
3.0
33.5
-
Note; the 5S series is delivered with a tapered washer and a round nut. 1 unipole model
EHP Fixed socket, nut fixing, protruding shell
Reference
Dimensions (mm)
Model
Series
a
b
e
e
L
L'
M
SI
S3
EHP
0S ✓
10
12.5
M9x0.6
2.5
17.5
18.5
12.5
8.2
11
EHP
1S ✓
14
16.0
M12x1.0
3.5
20.2
21.5
12.0
-
14
EHP
3S ✓
22
25.2
M18x1.0
4.0
29.0
30.0
18.7
-
22
20
/ Bei Lemo vorhanden I available at Lemo
Note; ' unipole model
