General Characteristics

Selection of the LEMO Fibre Optic Contacts

In order to ensure the highest technical performance and to provide the optimum solution for a diversity of applications, LEMO has developed four types of fibre optic contacts; designated F1, F2, F3, and F4. These contacts are designed to operate with single fibre, multi fibre, and mixed fibre optical/electrical cable constructions and cater to single and multi-mode fibres from 9/125 to 1500 urn diameter.

The choice of fibre optic contacts depends upon the following criteria:

- Cable construction (single fibre, multi fibre, mixed optical/electrical)

- Fibre type (single-mode or multi-mode).

The table below shows the suitability of each contact type with different fibres and cables.

Note that the multi fibre cable can contain many types of optic fibres or a group of fibres and electrical cables leading to mixed optical/electrical connectors.


	Contact type	Cable Structure		Fibre Types and dimensions
		, ^__		(-(4-
		single fibre	multi fibre or mixed	single-mode	multi-mode
		single fibre	multi fibre or mixed	single-mode	< 100/140um	> 100/140um
	F1
	F2
	F3


pcsa\|\| 1 [1=3,	F4

Series and contact configurations

Single and Multi F.O.

Mixed F.O. + L.V.


Number of F.O. contacts	Series
Number of F.O. contacts	0 0	0B	0K	2B-2K	3B-3K	4B-4K	5B-5K	3K.93C
1	•	•	•
2					•
4						•
10							•
14							•


Number of F.O. contacts	Number of L.V. electrical contacts	Series
Number of F.O. contacts	Number of L.V. electrical contacts	0 0	0B	0K	2B-2K	3B-3K	4B-4K	5B-5K	3K.93C
1	2, 4, 6 or 10				•
1	22					•
2	4, 6, 10 or 16					•
2	6, 7, 12, 16 or 18						•
3	6 or 12						•
3	10							•
4	5 or 9						•
9	3							_•

Note: • = available contact configuration

Mixed F.O. + L.V. + H.V.

Mixed F.O. + L.V. + Coax

Number

of F.O.

contacts

Number of L.V. electrical contacts

Number of H.V. electrical contacts

Series

0 0

2B-2K

3B-3K

4B-4K

5B-5K

3K.93C

•


Number of F.O. contacts	Number of L.V. electrical contacts	Number of coax electrical contacts	Series
Number of F.O. contacts	Number of L.V. electrical contacts	Number of coax electrical contacts	0 0	0B	0K	2B-2K	3B-3K	4B-4K	5B-5K	3K.93C
1	6	1					•
1	16	1					•
2	-	2						•
2	6	1						_•
