| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | LF 3000 polymer | | Applications | | | | | | | | | ■ used to connect pneumatic devices in many industrial applications : assembly machines, packaging equipment, factory automation, automotive process industry, textile machinery, printing machinery, vacuum networks ...etc The LF 3000 range meets the latest international standard ISO 14743, for push-in connectors manufacturer used in conjunction with thermoplastic tubes. Benefits ■ time saving and simplicity of installation : instant connection and disconnection without the use of tools | | | | | | | | | | | | | | full flow as gripping and sealing are achieved using the outside of the tube. immediate sealing : reinforced sealing by a captive 'O ring seal for parallel threaded fittings and pre-coating for taper threaded fittings. compactness and aesthetic: optimised dimensions and internal hexagons on straight fittings. orientable body for positioning purposes | | | | | | | | | | Technical specifications | | | | | | | | | | suitable fluids : compressed air LF3000® can also be used for conveying various types of liquids (water, cutting oil, etc) for industrial applications. The working pressure, from 0 to 6/10 bar, and temperatures, from 0 to 60°C, are dependent upon the fluid conveyed and the type of V ring used. For further information, please consult us. working pressure : 20 bar maximum vacuum capability : vacuum of 755 mm Hg (99% vacuum) working temperature : - 20° to + 80°C | | | | | | ■ a solution for all applications wide variety of body designs and numerous configurations from 3 to 14 mm diameters. -3 types of thread : BSP parallel and metric parallel, BSP taper. Special versions available on request - Please consult us. | | | | | | release button | | | | | | | | | | glass reinforced nylon 6.6 body | | | | | | | | | | sealing "O" ring | | | | | | | | | | | | | | sealing 'O' ring on BSPP threads and pre-coating on BSPT threads | | | | | | | | | | | | | | | | | | | | | | | | | | | | maximum tightening | Thread | M3 | M5 | M7 | G1/8" | G1/4" | G3/8" | G1/2" | | | | torque for LF 3000® fittings, BSPP and | x0,5 | x0,8 | x1 | | | | | | | | | | | | | | | | | | | metric threads | da N.m | 0,06 | 0,16 | 0,8 | 0,8 | 1,2 | 3 | 3,5 | | | | | | | | | | | | | | | | | | | | All items in the LF 3000 range are guaranteed silicone free. | | | | | | | | | | | | | | 6 | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
