CNC milling and engraving machine

IMPALA 200

The IMPALA 200 is a

compact CNC-controlled milling and engraving machine in column - design. The special characteristic of the IMPALA-series is the solid granite foundation which greatly reduces vibration and therefore guarantees high quality manufacturing. The Impala 200 is suitable for the manufacturing of coining dies, reliefs, moulds etc. in different materials and even stainless steel. The machine can be configured accordingly to each application by a wide range of accessories.

J Steel frame j Granite foundation

^Machine enclosure with viewing windows ^Working range X x Y x Z 300 x 200x 200 mm ^Clamping area X x Y 540 x 260 mm Machine dimensions

L x W x H 1.350 x 1.300 x 2.450 mm J Feed rate max. 5,2 m/min ^Weight of machine approx. 1.100 kg

Max. load (work piece and accessories) approx. 150 kg J4 axis motor control MCG 34 J Automatic toolchanger for 4 tools ^Milling-spindle

J Power: 1,6 kW

J Speed: 5.000-60.000 rpm

4 Tool fitting: Collet
