I Inline Series 6000 Specifications
10' conveyor front/back wipe-on configuration shown
Dimensions:
Height: 63.9" (1,623 mm) Length: 120" (3,048 mm) Width: 84.8" (2,154 mm)
Weight:
Approx. 1,000 lbs. (454 kg)
Electrical:
120 Volts AC 60 Hz 20 Amps. 220 Volts AC 50 Hz optional (CE)
Air:
A
38.0 34.0
"965.2m [863.6rr
I
~&—y~
r
I__51.0
r [1295.4
I (MAX) ] (MIN)
4 cfm at 90 psi to 100 psi required for air-blow and tamp-blow applications
Inches [millimeters]
Conveyor:
6' End-to end
8' End-to-end
10' End-to-end
12' End-to-end
Length
(Wrap only)
(Front/Back or Wrap)
(Front/Back and/or Wrap) (Front/Back and/or Wrap)
Width (Extrud. Alum. or SS Side Plates)
4.5" or 6.0"
4.5" or 6.0"
4.5" or 6.0"
4.5" or 6.0"
Height
36" ± 2"
36" ± 2"
36" ± 2"
36" ± 2"
Main Drive:
DC Motor
VFD
VFD/PLC
VFD/PLC
Line speed
Up to 1000"/min.
Up to 1200"/min
Up to 1200"/min
Up to 12007min
Applicator:
Label-Aire 3100 Series
Label-Aire 3100 Series
Label-Aire 3100 Series
Label-Aire 3100 Series
Primary Applicators
Primary Applicators
Primary Applicators
Primary Applicators
Operator Interface:
Electronic Box/
Electronic Box/
Electronic Box/
Electronic Box/
Applicators
Revolving Dual Keypad
Revolving Dual Keypad
Revolving Dual Keypad
Control
Analog
Digital/PLC
Digital/PLC
Digital/PLC
Top Hold Down:
N/A
~24", Linatex
~24" or 50.5", Linatex
~24" or 50.5", Linatex
Vertical Adjustment
N/A
12"
12"
12"
Belt Width
N/A
1"
1"
1"
Drive
N/A
VFD
VFD
VFD
Feedscrew:
N/A
Single or Dual
Single or Dual
Single or Dual
Length Options
N/A
24.0"
30.0"
30.0"
Drive
N/A
VFD
VFD
VFD
Soft Start
N/A
Yes
Yes
Yes
Metering Wheel (Optional):
Single
Single
Single
Single
Wheel Diameter
6.0"
6.0"
6.0"
6.0"
Drive
DC Motor
DC Motor
DC Motor
DC Motor
ASF (Optional):
N/A
Yes
Yes
Yes
Chain Aligner (Optional):
Drive
N/A
DC Motor
DC Motor
DC Motor
Wrap Belt (Optional):
(4.0" or 7.0") Wide x
(4.0" or 7.0") Wide x
(4.0" or 7.0") Wide x
(4.0" or 7.0") Wide x
12.0" Long
12.0" Long
12.0" Long
12.0" Long
Drive
DC Motor
VFD
VFD
VFD
Secondary Impressors (Optional):
Powered
DC Speed Control
DC Speed Control
DC Speed Control
DC Speed Control
Non-Powered
Available
Available
Available
Available
Consult factory for additional options.
ASF = Automatic Speed Following SS = Stainless Steel VFD = Variable Frequency Drive
label-aire"
labeling made easy
Europe
Sjaellandsuej 27A DK-9500 Hobro, Denmark
o +45 9657 0063 f +45 9657 0064 e info@label-aire.com w www.label-aire.com
Headquarters
550 Burning Tree Road Fullerton, CA 92833 USA
o 714.441.0700 f 714.526.0300 e info@label-aire.com w www.label-aire.com
Distributed by:
© 2003 Label-Aire
