3115 Wipe-On Specifications

Dimensions: Height: 30.41" (772.5 mm)Length: 33.44" (849.3 mm) Width: 22.84" (580 mm) Weight: 145 lbs. (65.7 kg) Standard Label Dimensions: Max. Web Width: 7.13" (181 mm) Min. Web Width: .63" (16 mm) Min. Label Length: .5" (13 mm) Label Packaging: 12" (305 mm) O.D. rolls std. on 3" (76 mm) I.D. coresUp to 16" (406 mm) or 20" (508 mm)roll with optional 16" (406 mm) non-powered rewind or 20" (508 mm) powered unwind
Inches[millimeters] Dispense Speed: Up to 1,500" (38.1 m) of web perminute (standard)Up to 2,000" (50.8 m) of web perminute with smart powered rewind
Stated dimensions are approximations. Please consult factory if dimensions are requiredfor line integration. Label Dispense Accuracy: Up to +/- 1/32" (.8 mm) Advanced Features Electrical:

3115 Wipe-On

115 Volts AC 60 Hz 3 Amps. 220 Volts AC 50 Hz optional Automatic setupStepper motor driveR3 digital displayAutomatic SpeedFollowing (ASF)Quick-actioncollapsible rewind Optional smartpowered rewind Wipe-On applicator Includes multiple programmable label pagesfor easy changeovers to different label sizes.For precise starting/stopping, increasedreliability, wider range speed variability, and lower maintenance.Select from five languages (English, French,German, Italian, Spanish), domestic or CE(European) configurations, standard/metricunit display and detailed alarm messages. Can rotate 360°in 90°increments.Labels are accurately applied even throughextreme changes in product line speed.Allows easy removal of scrap liner.For dynamic web tension control.Easily adapts to air-blow or tamp-blow use. Air (as needed): 2 cfm at 60 psi to 90 psi whenimprinter is used Options: 16" (406 mm) non-powered unwind Smart 10" (254 mm) powered rewindSmart 20" (508 mm) powered unwindand powered rewind*6" (152 mm) label core adapter Encoder kit for AutomaticSpeed FollowingStrobe signals for “low label” and“out of labels”Clear label sensor upgrade Hot stamp imprinter Display tilt mounting brackets Model 2700 T-Base stand Consult factory for additional options. * 4.13" (105 mm) wide applications only
labeling made easy Headquarters Europe Asia
550 Burning Tree RoadFullerton, CA 92833 USA Sjællandsvej 27ADK-9500 Hobro, Denmark No. 10, Lane 228, Taisi S. Road Longjing Township Taichung County 434, Taiwan Distributed by: o
714.441.0700 o
+45.9657.0063 o
+886.4.2395.5684 f
714.526.0300 f
+45.9657.0064 f
+886.4.2395.8007 e
info@label-aire.com e
info@label-aire.com e
info@label-aire.com w
www.label-aire.com w
www.label-aire.com w
www.label-aire.com ©2008 Label-Aire Rev. C 9/08
