Écrous à sertir en aveugle Écrous à sertir en aveugle

Blind Rivet Nuts Blind Rivet Nuts Matière : Aluminium

Material : Aluminium Material : Aluminium

Matière : Aluminium Tête : Af eurante

Head : Flush Head : Flush

Tête : Af eurante Fût : Cylindrique

Body : Round Body : Round

Fût : Cylindrique Extrémité du fût : Ouvert

Body end : Open Shape Body end : Closed End

Extrémité du fût : Borgne

S = X - EpLs = L - X - 0.1 S = X - EpLs = L - X - 0.1 Lus = Lu - S

Outillages de pose Outillages de pose Fastening tools Fastening tools

se référer à / refer to se référer à / refer to

TOOLIN'FIX TOOLIN'FIX

Ø M Code Ø A L E Ø D X L Ø D Ø M Code Ø A L L.u E Ø D X E X

indicative data indicative data in d i ca tiv e da t a

M2.5 x 0.45 0.0 - 1.1 01U025ARO011X 4.0 4.6 6.4 0.3 4.0 2.4 165 0.6 0.6 0.1 0.8 - 1.7 01U025ARO017X 4.0 4.6 7.0 0.3 4.0 3.0 165 0.6 0.6 0.1 M3 x 0.50 0.0 - 1.1 01U030ARO011X 5.0 5.8 7.2 0.3 5.0 2.4 225 0.8 0.8 0.2 1.0 - 2.3 01U030ARO023X 5.0 5.8 8.6 0.3 5.0 3.6 225 0.8 0.8 0.2 2.1 - 3.2 01U030ARO032X 5.0 5.8 9.7 0.3 5.0 4.7 225 0.8 0.8 0.2 3.0 - 4.1 01U030ARO041X 5.0 5.8 10.6 0.3 5.0 5.6 225 0.8 0.8 0.2 M4 x 0.70 0.0 - 1.3 01U040ARO013X 6.0 6.8 9.4 0.3 6.0 2.6 400 1.9 1.9 0.3 0.5 - 3.0 01U040ARO030X 6.0 6.8 11.1 0.3 6.0 4.3 400 1.9 1.9 0.4 1.8 - 4.2 01U040ARO042X 6.0 6.8 12.3 0.3 6.0 5.5 400 1.9 1.9 0.4 3.5 - 5.5 01U040ARO055X 6.0 6.8 13.5 0.3 6.0 6.8 400 1.9 1.9 0.4 M5 x 0.80 0.0 - 1.5 01U050ARO015X 7.0 8.0 10.8 0.4 7.0 3.0 650 3.8 3.2 0.5 0.0 - 2.5 01U050ARO025X 7.0 8.0 11.8 0.4 7.0 4.0 650 3.8 3.2 0.5 0.5 - 3.5 01U050ARO035X 7.0 8.0 12.8 0.4 7.0 5.0 650 3.8 3.2 0.6 1.5 - 4.5 01U050ARO045X 7.0 8.0 13.8 0.4 7.0 6.0 650 3.8 3.2 0.6 M6 x 1.00 0.0 - 1.5 01U060ARO015X 9.0 10.0 13.3 0.4 9.0 3.4 1100 6.7 6.0 1.2 1.0 - 3.5 01U060ARO035X 9.0 10.0 15.3 0.4 9.0 5.4 1100 6.7 6.0 1.3 2.0 - 4.5 01U060ARO045X 9.0 10.0 16.3 0.4 9.0 6.4 1100 6.7 6.0 1.3 3.0 - 5.5 01U060ARO055X 9.0 10.0 17.3 0.4 9.0 7.4 1100 6.7 6.0 1.4 4.0 - 6.5 01U060ARO065X 9.0 10.0 18.3 0.4 9.0 8.4 1100 6.7 6.0 1.4 M8 x 1.25 0.0 - 1.8 01U080ARO018X 11.0 12.0 14.7 0.4 11.0 3.7 1750 16.2 10.5 1.7 0.0 - 3.0 01U080ARO030X 11.0 12.0 15.9 0.4 11.0 4.9 1750 16.2 10.5 1.8 1.3 - 4.2 01U080ARO042X 11.0 12.0 17.2 0.4 11.0 6.2 1750 16.2 10.5 1.9 2.0 - 5.0 01U080ARO050X 11.0 12.0 17.8 0.4 11.0 6.9 1750 16.2 10.5 1.9 3.5 - 6.5 01U080ARO065X 11.0 12.0 19.3 0.4 11.0 8.4 1750 16.2 10.5 2.0 M10 x 1.50 0.0 - 3.2 01U100ARO032X 13.0 14.5 20.6 0.6 13.0 6.0 2200 32 16.4 3.0 2.0 - 5.5 01U100ARO055X 13.0 14.5 22.9 0.6 13.0 8.3 2200 32 16.4 3.2 3.0 - 6.5 01U100ARO065X 13.0 14.5 23.9 0.6 13.0 9.3 2200 32 16.4 3.3 4.5 - 7.5 01U100ARO075X 13.0 14.5 24.9 0.6 13.0 10.3 2200 32 16.4 3.4 M12 x 1.75 0.0 - 4.2 01U120ARO042X 16.0 17.5 24.3 0.6 16.0 7.3 3000 55 23.5 5.4 2.0 - 6.0 01U120ARO060X 16.0 17.5 26.1 0.6 16.0 9.1 3000 55 23.5 5.7 3.5 - 7.6 01U120ARO076X 16.0 17.5 27.7 0.6 16.0 10.7 3000 55 23.5 5.9 6.0 - 9.2 01U120ARO092X 16.0 17.5 29.2 0.6 16.0 12.3 3000 55 23.5 6.1 M14 x 2.00 0.0 - 3.0 01U140ARO030X 18.0 19.5 26.6 0.6 18.0 7.0 3600 89 31.5 7.5 1.0 - 5.0 01U140ARO050X 18.0 19.5 28.6 0.6 18.0 9.0 3600 89 31.5 8.0 3.0 - 7.0 01U140ARO070X 18.0 19.5 30.6 0.6 18.0 11.0 3600 89 31.5 8.4 6.0 - 9.0 01U140ARO090X 18.0 19.5 32.6 0.6 18.0 13.0 3600 89 31.5 8.8 M16 x 2.00 0.0 - 3.2 01U160ARO032X 21.0 22.5 28.0 0.6 21.0 8.2 5900 139 41 10.6 0.0 - 5.7 01U160ARO057X 21.0 22.5 30.5 0.6 21.0 10.7 5900 139 41 11.2 2.0 - 8.2 01U160ARO082X 21.0 22.5 32.9 0.6 21.0 13.2 5900 139 41 11.9 6.0 - 11.0 01U160ARO110X 21.0 22.5 35.7 0.6 21.0 16.0 5900 139 41 12.6 M2.5 x 0.45 0.0 - 1.1 01U025ARB011X 4.0 4.6 9.7 5.6 0.3 4.0 2.4 165 0.6 0.6 0.2 0.8 - 1.7 01U025ARB017X 4.0 4.6 10.3 6.5 0.3 4.0 3.0 165 0.6 0.6 0.2 M3 x 0.50 0.0 - 1.1 01U030ARB011X 5.0 5.8 11.9 6.7 0.3 5.0 2.4 225 0.8 0.8 0.4 1.0 - 2.3 01U030ARB023X 5.0 5.8 13.1 8.2 0.3 5.0 3.6 225 0.8 0.8 0.4 2.1 - 3.2 01U030ARB032X 5.0 5.8 13.8 8.7 0.3 5.0 4.7 225 0.8 0.8 0.4 3.0 - 4.1 01U030ARB041X 5.0 5.8 14.7 9.6 0.3 5.0 5.6 225 0.8 0.8 0.4 M4 x 0.70 0.0 - 1.3 01U040ARB013X 6.0 6.8 15.1 8.5 0.3 6.0 2.6 400 1.9 1.9 0.7 0.5 - 3.0 01U040ARB030X 6.0 6.8 16.7 10.1 0.3 6.0 4.3 400 1.9 1.9 0.7 1.8 - 4.2 01U040ARB042X 6.0 6.8 18.0 11.4 0.3 6.0 5.5 400 1.9 1.9 0.7 3.5 - 5.5 01U040ARB055X 6.0 6.8 19.5 12.9 0.3 6.0 6.8 400 1.9 1.9 0.7 M5 x 0.80 0.0 - 1.5 01U050ARB015X 7.0 8.0 16.8 10.5 0.4 7.0 3.0 650 3.8 3.2 0.9 0.0 - 2.5 01U050ARB025X 7.0 8.0 17.8 11.5 0.4 7.0 4.0 650 3.8 3.2 1.0 0.5 - 3.5 01U050ARB035X 7.0 8.0 19.3 13.0 0.4 7.0 5.0 650 3.8 3.2 1.0 1.5 - 4.5 01U050ARB045X 7.0 8.0 20.3 14.0 0.4 7.0 6.0 650 3.8 3.2 1.1 M6 x 1.00 0.0 - 1.5 01U060ARB015X 9.0 10.0 21.3 12.5 0.4 9.0 3.4 1100 6.7 6.0 2.2 1.0 - 3.5 01U060ARB035X 9.0 10.0 23.3 14.5 0.4 9.0 5.4 1100 6.7 6.0 2.3 2.0 - 4.5 01U060ARB045X 9.0 10.0 24.3 15.5 0.4 9.0 6.4 1100 6.7 6.0 2.3 3.0 - 5.5 01U060ARB055X 9.0 10.0 25.3 16.5 0.4 9.0 7.4 1100 6.7 6.0 2.4 4.0 - 6.5 01U060ARB065X 9.0 10.0 26.3 17.5 0.4 9.0 8.4 1100 6.7 6.0 2.4 M8 x 1.25 0.0 - 1.8 01U080ARB018X 11.0 12.0 24.2 13.7 0.4 11.0 3.7 1750 16.2 10.5 3.4 0.0 - 3.0 01U080ARB030X 11.0 12.0 25.4 14.9 0.4 11.0 4.9 1750 16.2 10.5 3.4 1.3 - 4.2 01U080ARB042X 11.0 12.0 26.7 16.2 0.4 11.0 6.2 1750 16.2 10.5 3.5 2.0 - 5.0 01U080ARB050X 11.0 12.0 27.5 16.8 0.4 11.0 6.9 1750 16.2 10.5 3.7 3.5 - 6.5 01U080ARB065X 11.0 12.0 28.5 18.0 0.4 11.0 8.4 1750 16.2 10.5 3.7 M10 x 1.50 0.0 - 3.2 01U100ARB032X 13.0 14.5 31.9 21.4 0.6 13.0 6.0 2200 32 16.4 5.6 2.0 - 5.5 01U100ARB055X 13.0 14.5 34.4 23.0 0.6 13.0 8.3 2200 32 16.4 5.9 3.0 - 6.5 01U100ARB065X 13.0 14.5 35.4 24.0 0.6 13.0 9.3 2200 32 16.4 6.0 4.5 - 7.5 01U100ARB075X 13.0 14.5 36.4 25.0 0.6 13.0 10.3 2200 32 16.4 6.1 M12 x 1.75 0.0 - 4.2 01U120ARB042X 16.0 17.5 36.3 23.7 0.6 16.0 7.3 3000 55 23.5 9.8 2.0 - 6.0 01U120ARB060X 16.0 17.5 38.2 25.6 0.6 16.0 9.1 3000 55 23.5 10.1 3.5 - 7.6 01U120ARB076X 16.0 17.5 39.7 27.0 0.6 16.0 10.7 3000 55 23.5 10.3 6.0 - 9.2 01U120ARB092X 16.0 17.5 41.3 28.5 0.6 16.0 12.3 3000 55 23.5 10.5 M14 x 2.00 0.0 - 3.0 01U140ARB030X 18.0 19.5 41.6 27.6 0.6 18.0 7.0 3600 89 31.5 14.0 1.0 - 5.0 01U140ARB050X 18.0 19.5 43.6 29.6 0.6 18.0 9.0 3600 89 31.5 14.4 3.0 - 7.0 01U140ARB070X 18.0 19.5 45.6 31.6 0.6 18.0 11.0 3600 89 31.5 14.9 6.0 - 9.0 01U140ARB090X 18.0 19.5 47.6 33.6 0.6 18.0 13.0 3600 89 31.5 15.3 M16 x 2.00 0.0 - 3.2 01U160ARB032X 21.0 22.5 44.1 27.2 0.6 21.0 8.2 5900 139 41 20.2 0.0 - 5.7 01U160ARB057X 21.0 22.5 46.5 29.6 0.6 21.0 10.7 5900 139 41 20.8 2.0 - 8.2 01U160ARB082X 21.0 22.5 48.9 32.0 0.6 21.0 13.2 5900 139 41 21.5 6.0 - 11.0 01U160ARB110X 21.0 22.5 51.9 34.7 0.6 21.0 16.0 5900 139 41 22.2 Écrou à sertir en aveugle correspondant à l’ancienne désignation M ... fO ... ALUMINIUM Écrou à sertir en aveugle correspondant à l’ancienne désignation M ... fB ... ALUMINIUM

Blind Rivet Nuts corresponding to old designation M ... fO ... ALUMINIUM Blind Rivet Nuts corresponding to old designation M ... fB ... ALUMINIUM
