| | | ter-On-Modules | | |
| | | |
| | | Computer-On-Modules are the perfect solution for embedded medical applications that require full PC functionality and high performance on x86 or RISC architecture. | | The full-featured COMs include onboard USB, much like an integrated circuit component. Ethernet, graphics, sound, such as keyboard, Kontron offers as well the design and produc- serial, parallel and IDE interfaces. COMs are tion services for your customized baseboard, installed on application-specific baseboards. | | Programmer for medical pacemakers | | |
| | | |
| | | A compact system featuring an intuitive software environment, the programmer is intended specifically for clinical practice. Throughout all stages of development, and especially during the clinical phases, the programmer was designed via close co-operation between cardiologists and the engineers. The outcome is an intuitive programmer ensuring superior working comfort for users. Kontron did the complete ETX-based engineering, programming and manufacturing for a leading OEM customer. | | |
| | | |
| | | Advantages of the modules at a glance | | Application examples | | |
| | | |
| | | |
| | | > Compliant to medical standards > Adaptive to different medical interfaces > Scaleable due to interchangeable modules > Longevity / High reliability > Proven, open module standard > Made for use in ambulant & permanent client environment > Dust and splash water proof use > Backup battery support | | Certified, Medical Panel This high tech modular medicine-PC, which is characterised by its complete sealed housing (IP65). It corresponds to the certification of EN60601-1 and EN60601-1-2. This panel is used in the operation theatre e.g.in radiology and endoscope. It can be easily configured to meet the customers needs. The heart of this medical panel is the Kontron ETX-PM. | | |
| | | New generation of cardiovascular ultrasound | | |
| | | |
| | | The incredible system establishes a completely new level of cardiovascular performance that gives clinicians the freedom to get diagnostic results outside of the echo lab. The heart of this medical device is the Kontron ETX-PM Computer-on-Module. Robust diagnostic exams can now be performed at the patient's bedside, satellite clinics or mobile imaging sites, and the OR - wherever they are needed to give clinicians access to complete real-time diagnostic information. | | |
| | | |
| | | Customized Baseboards > Tailor-made for your needs > Customised baseboard > The one-stop shop for your perfect-fit baseboard | | |
| | | |
| | | |
| | | |
| | | Clinical Workstation | | Mobile Patient Monitoring | | |
| | | |
| | | |
| | | The Clinical Workstation is one of the most advanced medical PC systems on the market. Approved and certified by a Kontron partner to operate as a data-collector in the operating theatre this machine is connected to several technical devices and records all steps and events taking place during the surgery. The powerful Kontron ETX-PM, powered by an Intel® Pentium® M processor, allows handling several real time data connections simultaneously together with a high solution graphical user interface. The complete system operates fanless in a fully closed chassis. The system is extremely flat (85 mm) and waterproof according to IP65. | | The system makes it unbelievably easy and cost-effective for the clinician to bring leadership technology to a wide range of application, such as cardiac, vascular, pediatrics and transesophageal. In emergency medicine and the rescue services, every second counts, and getting the right information at the right time is vital. For the first time, UMTS technology offers digital data exchange options with performance high enough that the technology can be used by the emergency medical services. The Mobile Medical system platform implements a patient monitoring application from a medical technology provider using UMTS and based on Kontron ETX Computer-On-Modules. | | |
| | | |
| | | |
