The appropriate System for your Performance Summary of Plasma Cutting Units appointed for Robots Cutting current (A) Recommended thickness for quality cut (mm) Maximum Thickness Plasma torch Hi 80i Focus 4 - 80 0.5 - 18 25 PerCut 160-2 3D-Cut 80 Hi 130 Focus 20 - 130 0.5 - 32 40 PerCut 160-2 (3D-Cut 80) Hi 160i Focus 4 - 160 0.5 - 38 50 PerCut 160-2 (3D-Cut 80) Fine 450 Focus 40 - 130 3 - 35 45 PB-S47 W-2 Fine 800 Focus 80 - 300 3 - 60 80 PB-S80 W-2 Fine 1600 Focus 160 - 600 30 - 110 160 PB-S151 W-2 PA-S45 W 45/85/130 3 - 30 45 PB-S45 W-2 PA-S25 W 25/45/70 3 - 15 25 PB-S45 W-2 Workpiece cable Gas hoses PBL max. 55 m FINEFOCUS 6.xx PBA Plasma torch 1,5 m PGE N2 O2 N H 2 2 N2 H2 Ar O2 Air Plasma gases Swirl gases FF FF FF Configuration of a Robot Cutting Station (For all gases, cutting of mild steel, CrNi-materials, Aluminium etc.) The robot. cutting station will be completed by workpiece positioner, fume extraction for removal of contaminants and safety arrangements for the personnel. Legend: PGE Plasmagas Control Unit PBL Cable Set PBA Plasmatorch Connection Unit FF Filter / Fine filter All plasma torches are fluid-cooled Plasma power source Kjellberg Finsterwalde Plasma und Maschinen GmbH Germany D - 03238 Finsterwalde Leipziger Str. 82 Phone: +49 3531 500-0 Fax: +49 3531 500-227 E-mail: plasma@kjellberg.de Internet: www.kjellberg.de 10-06-01 Copyright 2010 Kjellberg Finsterwalde Plasma und Maschinen GmbH All rights reserved. , , , HiFocus PGC, XL and YellowXLife are trademarks of the Kjellberg Foundation/ Kjellberg Finsterwalde and may be registered in Germany and/or other countries. FINEFOCUS , Kjellberg-plasma cutting units are and correspond with the valid guidelines and instructions of the European Union. They are developed and fabricated on basis of following standards and instructions: . The plasma cutting units are labelled with the and therefore applicable to environments with increased hazard of electric shock. The fabrication takes place according to . The factory-owned quality assurance comprises piece and cutting performance tests, documented by test certificate. Our products represent a high level of quality and reliability. We reserve the rights to change design and/or technical specification during the series fabrication. Claims of any kind cannot be derived from this prospectus. CE-conform EN 60974 (VDE 0544) S-sign DIN EN ISO 9001
