NEW!

Laser welder fillers

JOKE® Fill


Welding filler JOKE® Fill 160 - Laser	Design	Dimensions	Weight	Order No. Price €
Cr-Mo-Mn-W-V filler with extremely wear-proof	Spool 50 g	0 0.3 mm	50 g	0 084 213
and tough hardened characteristics. Suitable for hard build-up layers on cold-work steels with more than 5 % chrome content. Crack-proof and fast hardening, good edge stability. Thermally treatable		0 0.4 mm	50 g	0 084 214
		0 0.5 mm	50 g	0 084 215
		0 0.6 mm	50 g	0 084 216
like parent material. The weld metal is nitritable, erodible, chrome platable and heat treatable.
	Spool 150 g	0 0.3 mm	150 g	0 084 213-2
Hardness first layer: ca. 58-60 HRC, depending on		0 0.4 mm	150 g	0 084 214-2
composition. Can be hardened to ca. 62 HRC.		0 0.5 mm	150 g	0 084 215-2
Base composition %: C 0.35 • S <0.002 • Cr 6.40 •		0 0.6 mm	150 g	0 084 216-2
Base composition %: C 0.35 • S <0.002 • Cr 6.40 •
P 0.02 • Mo 2.00 • Ti 0.25 • Fe remainder
	Spool 500 g	0 0.3 mm	500 g	0 084 213-4
Suitable for material Nos. 1.2358 • 1.2363 • CARMO • CALVAX and similar		0 0.4 mm	500 g	0 084 214-4
		0 0.5 mm	500 g	0 084 215-4
		0 0.6 mm	500 g	0 084 216-4

	Rod 300 mm	0 0.3 mm	150 g	0 084 213-7
		0 0.4 mm	150 g	0 084 214-7
		0 0.5 mm	150 g	0 084 215-7
		0 0.6 mm	150 g	0 084 216-7


Welding filler JOKE® Fill 165 - Laser	Design	Dimensions	Weight	Order No. Price €
Cr-Mn-Si-V welding filler with structure-stabilising	Spool 50 g	0 0.1 mm	50 g	0 084 231
elements. Not chrome platable, but nitritable and erodible. The weld metal is very similar to 12 % Cr steels.		0 0.2 mm	50 g	0 084 232
		0 0.3 mm	50 g	0 084 233
		0 0.4 mm	50 g	0 084 234
Hardness first layer: ca. 58-60 HRC, depending on composition. Can be hardened to ca. 62 HRC.		0 0.6 mm	50 g	0 084 236

Base composition %: C 0.35 • Cr 9.00 • Mn 0.70 •	Spool 150 g	0 0.1 mm	150 g	0 084 231-2
Si 0.70 • V 0.30 Fe remainder		0 0.2 mm	150 g	0 084 232-2
Suitable for material No. 1.2379 • 1.2080 • 1.2436 • 1.2601 and similar		0 0.3 mm	150 g	0 084 233-2
		0 0.4 mm	150 g	0 084 234-2
		0 0.6 mm	150 g	0 084 236-2

	Spool 500 g	0 0.2 mm	500 g	0 084 232-4
		0 0.3 mm	500 g	0 084 233-4
		0 0.4 mm	500 g	0 084 234-4
		0 0.6 mm	500 g	0 084 236-4

	Rod 300 mm	0 0.3 mm	150 g	0 084 233-7
		0 0.4 mm	150 g	0 084 234-7
		0 0.6 mm	150 g	0 084 236-7
