Mobile grinding, milling and polishing system ENESKA 1

► E NESKA 1 - Performance in a pocket format

Compact, handy system with battery operation. The ENESKA 1 can be used anywhere where the work-piece is hard to get at or would need to be removed from the production equipment at great time cost. Its compact case contains mature technology, based on the tried and tested "big" ENESKA 3-1-System. The micromotor can optionally be fitted with either a rapid-chuck handpiece or an angle handpiece.

Complete Set ENESKA 1

Order No. Price €

The set comes in a plastic case and contains:

1 x control unit NE-77A (Order No. 0 009 713-0)

1 x micromotor NCL-25-SS (Order No. 0 009 711)

1 x tray (Order No. 0 009 712-0)

1 x rapid-chuck handpiece VH-E (Order No. 0 009 715)

including collets 2,35 and 3,0 mm 1 x charger NE-106-03 (Order No. 0 009 714-0) 1 x handpiece receptacle (Order No. 0 009 004)

0 009 700-0

Control unit NE-77A

Order No. Price €

Continuous rotation speed adjustment 2,000 - 30,000 rpm

Efficient NiCad battery for mobile operation

(approx. 1 hour charging time / 1 hour continuous operation)

Left / right operation

Hand / foot operation

Dimensions (w x h x d) 72 x 163 x 95 mm Weight 400 g

Output voltage 10 V DC

0 009 713-0


		Order No. Price €
	Motor cable NCL-25-CD-V	0 009 712-0
	To connect micromotor NCL-25-SS with control unit NE-77A,
	length: 0.6 - 1.5 m (helical cable), weight: 57 g

	Charger NE-106-03	0 009 714-0
	for recharging control unit battery NE-77A,
	Supply: 230 V, 50/60 Hz
	Foot switch FC 25	0 009 701
	Foot can be used to adjust rotation speed and start/stop

Accessories ENESKA 1
